Firma 780Kv Brushless Motor

The Spektrum Firma 780Kv Brushless Motor (SPMXSM1100) is built for large-scale RC power, delivering smooth, efficient performance on 3–8S LiPo systems. A low-cog 4‑pole, 8‑magnet rotor teams with a CNC‑machined aluminium housing featuring heat‑sinking fins for robust cooling and durability. High‑purity copper windings, precision bearings and a hardened 8 mm output shaft provide reliable torque delivery and long service life. Preinstalled 6.5 mm gold‑plated bullet connectors simplify installation, and the motor is perfectly matched to the Spektrum Firma 160 Smart ESC.

Key Features

• Heat‑sinking designed CNC aluminium housing
• 8S LiPo power capable
• High efficiency design
• High‑quality 4‑pole sintered rotors
• Includes 6.5 mm gold‑plated bullet connectors
• Precision ball bearings and hardened steel 8 mm shaft

Specifications

• Motor design: Inrunner
• Outer diameter: 2.2 in (56 mm)
• Product width: 2.2 in (56 mm)
• Product length: 4.45 in (113 mm)
• Weight: 43 oz (1220 g)
• Shaft diameter: 5/16 in (8 mm)
• Number of poles: 4
• RPM/Volt (Kv): 780Kv
• Input voltage: 11.1–29.6 V (3–8S LiPo)
• Maximum continuous current: 200 A
• Output: 6365 W (6S LiPo)
• Wire gauge: 10 AWG
• Connector type: 6.5 mm bullet
• Bushing or bearing: Bearing
• Motor type: Brushless
• Efficiency: 90%
• Recommended speed control: Spektrum Firma 160 Smart ESC

Suggested Compatibility

• 1/5th scale RC vehicles operating on 3–8S LiPo power systems
