Reedy Sc480X Program Card

Brand: Reedy

Part No: AS27034

£18.04 ~~RRP £18.99~~

Shadow Stock: Usually ships next day

Request Price Match Ask a Question Write a Review

Unlock fine-tuning of your ESC with the Reedy SC480X Program Card (AS27034). While factory defaults suit most driving, this optional card gives quick access to additional parameters so you can refine throttle feel, braking behaviour and battery protection to match track conditions and driving style.

Adjustable Settings

Initial Drive: Throttle applied the moment the trigger moves from neutral.
Low-Voltage Cutoff: Cell voltage level where the ESC shuts off to protect the battery.
Drag Brake: Brake force when the throttle trigger returns to neutral.
Max Reverse Power: Maximum reverse speed allowed relative to forward speed.
Punch Control: Aggressiveness of throttle application.

Available Setting Values

Initial Drive: 2%, 5% (default), 10%, 15%
Low Voltage Cutoff (V/cell): 3.2, 3.3, 3.4 (default)
Drag Brake: 0%, 50%, 75%, 100% (default)
Max Reverse Power: 50%, 75% (default), 100%
Punch Control: Soft (default), Medium, Strong

Suggested Compatibility

Reedy SC480X ESC

A straightforward way to access and adjust key ESC settings, the Reedy SC480X Program Card helps optimise performance with simple, repeatable changes using part number AS27034.

Free Shipping

On UK Orders over £100

Happy to Help

Helpful, friendly advice

28 Day Returns

Easy returns process

Secure Payments

Secured by Stripe

REEDY SC480X PROGRAM CARD

The pre-programmed default ESC settings work very well in most situations, but if you want access to additional settings for fine-tuning, you can do so using optional Program Card (#27034). The following settings can be changed using the Program Card:

Initial Drive: Throttle applied the moment the trigger is moved from the neutral position to the throttle range.
Low-Voltage Cutoff: The cell voltage at which the ESC will shut off to protect the battery.
Drag Brake: The brake force applied when the throttle trigger is returned to the neutral position.
Max Reverse Power: The maximum reverse speed allowed relative to the forward speed.
Punch Control: The aggressiveness of the application of throttle.

Specifications

Header: Setting / Value
Initial Drive: 2%, 5%*, 10%, 15%
Low Voltage Cutoff (V/cell): 3.2, 3.3, 3.4*
Drag Brake: 0%, 50%, 75%, 100%*
Max Reverse Power: 50%, 75%*, 100%
Punch Control: Soft*, Medium, Strong
Header: *Default setting

Key Info:

Brand: Reedy
Part No: AS27034
Barcode: 784695270343

Standard Shipping

£3.95 to most of the UK

Express Shipping

£6.95 to most of the UK

Worldwide Shipping

Available at checkout

Reviews

No specific product reviews yet, why not write one?

WRITE A REVIEW

Name

Rating

Your Review

All reviews are subject to moderation

Questions & Answers

Real questions from real customers. Why not ask your own?

Will this work with reedy sc600-bl. ESC????

Mark / 9th June 2023

No that esc is not programmable by a card.
