XRay Composite Upright 0 Deg Outboard Toe-In - 1-Hole - Hard - Rubber-Spec
XRay Composite Upright 0 Deg Outboard Toe-In - 1-Hole - Hard - Rubber-Spec
XRay Composite Upright 0 Deg Outboard Toe-In - 1-Hole - Hard - Rubber-Spec
XRay Composite Upright 0 Deg Outboard Toe-In - 1-Hole - Hard - Rubber-Spec

XRay Composite Upright 0 Deg Outboard Toe-In - 1-Hole - Hard - Rubber-Spec

Brand: XRay

Part No: XR303364

£8.84 RRP £9.31

Shadow Stock: Usually ships within 2 days

Collect Instore
Request Price Match Ask a Question Write a Review

The XRay Composite Upright 0 Deg Outboard Toe-In – 1-Hole – Hard – Rubber-Spec (XR303364) is a moulded rear upright with 0° outboard toe-in to improve traction and help reduce suspension geometry changes during heavy impacts. The single, central camber link hole suits high-traction tracks and long sweepers, aiding corner speed. Hard “H” composite is optimised for foam tyres but also works with rubber.

Highlights

  • 0° outboard toe-in rear upright for enhanced traction and stability
  • Single (1-hole) camber link position suited to high-grip tracks and long sweepers
  • Roll centre can be adjusted by adding shims between the upright and the turnbuckle ball joint
  • Uses compact 5x10x4mm ball bearings to minimise unsprung weight
  • Hard Rubber-Spec composite: foam-tyre optimised, compatible with rubber tyres
  • Usable on both left and right sides

Suggested Compatibility

  • XRAY T3
  • XRAY T4
Free Shipping

On UK Orders over £100
Happy to Help

Helpful, friendly advice
28 Day Returns

Easy returns process
Secure Payments

Secured by Stripe

This is a XRAY Hard Composite Rubber-Spec Rear Upright, and is intended for use with the XRAY T3 touring car. This molded-composite rear upright features built-in 0° of outboard toe-in to improve traction and prevent suspension geometry changes in serious crashes. This 1-hole upright is recommended for use on high-traction tracks or tracks with long sweepers, since the position of the center hole will allow the chassis to carry more corner speed. More roll center positions can be easily adjusted by adding shims between the upright and the turnbuckle ball joint. The rear upright feature small but robust 5x10x4 ball-bearings to minimize un-sprung weight.

Hard rigidity (labeled “H”) composites are specially optimized for foam-tire racing, but can also be used with rubber tires. For use on both left and right sides of the car.

Part Compatibility:
  • XRAY T3
  • XRAY T4


    • Key Info:
    • Brand: XRay
    • Part No: XR303364
    • Barcode: 8581703033646
    • Fitment: Option Part
