Absima AB3.4 Kit
Brand: Absima
Part No: AB-12222KIT
SORRY, THIS ITEM IS DISCONTINUED AND NO LONGER AVAILABLE.
Why not contact our team to see if an alternative is available?
Description
Fast and powerful - the new Hotshot 3.4 series is equipped with a powerful brushed electric motor - with heat sink - and waterproof electronic speed controller (ESC). Ready to run out of the box (EU & UK version including plug charger and battery). Shaft driven 4WD provides you with the necessary traction to maneuver the toughest obstacles and the forward/reverse ESC is beneficial in navigating tight spots. Lightweight plastic chassis - four oil filled adjustable coil over shocks - and independent suspension offer rock solid performance. Fear not! A 2.4GHz radio system and waterproof electronics ensure control - for those who dare to unleash the power.
HIGHLIGHTS
KIT Version for self assembling
Racing Body Design
Including 2 Versions of Motor Transmissions for Brushed & Brushless (Steel Version)
NOTE: KIT Version don`t includes any electronic components!
PRODUCT FEATURES
Ball bearing transmission
Oil filled adjustable shocks
Gear differential front/rear
Aluminum motor mount
Complete covered transmission
Adjustable turnbuckles & wishbones
Motor heat sink
Aero disc racing wheels
Full printed body
Sticker sheet for a unique design
Performance hop ups available!
TECH SPECS
Drive System: 4 Wheel Drive
Wheelbase: 270mm
Ground Clearance: 35mm
Measure (L/W/H): 380x255x155 mm
Weight: 1410g
Tire width: 33 mm front / 42 mm rear
Tire ? ? 88 mm
Shock spring force: medium / Length: 85mm f/r
Differential oil viscosity: 3.000 front /1.000 rear
Shock oil viscosity: 400 f/r
Motor transmission: Pinion 23T / Gear 64T
Pinion module: 0.6
SCOPE OF DELIVERY
Buggy AB3.4 KIT version
Manual
Sticker Sheet
REQUIRED ACCESSORIES
Radio System
Steering Servo + Servo Horn
Electric Speed Controller (brushed or brushless)
540size Electric Motor (brushed or brushless)
Battery - Racing Pack NiMH or LiPo (up to 30C)
Charger
4x AA Mignon Batteries for Radio
Secured by Stripe
Specifications
- Brand: Absima
- Part No: AB-12222KIT
- Barcode: 4250650937508
- Scale: 1:10
- Vehicle Type: Buggy
- Power Source: Electric - No Motor
- Surface Type: Off Road
- Build Level: Unassembled (Kit)
Delivery & Returns
Standard Shipping
£3.95 to most of the UK
Express Shipping
£6.95 to most of the UK
Worldwide Shipping
Available at checkout
Customer Reviews
Great value kit, ran this buggy on the upgraded Eco Brushless combo set 2120002 with Lipo battery makes it quick. The small negatives would be that the instructions are poor and there were bottom hub screws missing + the standard plastic Gear comes pre assembled on the diff so you need to heat the loctite and remove before re fitting the metal one ready for brushless use. Overall super value for money and very quick , glad I bought it during this Lock down, great fast delivery too, thanks Wheelspin
Questions & Answers
No I think that's overkill.... You want a 1:8 buggy to do that
Most of it is built , you just bolt all the parts to the chassis.
These have ball bearings
They do include a 25T (Futaba style) servo horn
Yes - you could fit a brushless setup no problem. There's no modifications you'd need.
This is a kit, so requires electronics and assembly.
The Ready To Run (RTR) version is AB-12222
No, these don't have a slipper clutch
For more in depth queries, please contact us.
