Dubro DB796 80oz (2400cc) Fuel Tank
Brand: Dubro
Part No: DUB796
Shadow Stock: Usually ships next day
The Dubro DB796 80oz (2400cc) Fuel Tank delivers dependable fuel storage for longer flights in large scale aircraft. Built to DU-BRO’s renowned standards using quality blow-moulded construction, it is designed for durability and reliable performance. The tank can be used with pressurised fuel systems and comes with the essential fittings specified by the manufacturer. For easy installation planning, key dimensions and weight are provided below.
Identified by part number DUB796, this 80oz tank includes a petrol bung as standard, an easy-bend brass pickup tube, and a large nickel-plated clunk to maintain consistent fuel delivery throughout the flight envelope.
Key Features
- 80oz (2400cc) capacity for extended flight times
- 5/32 easy-bend brass tube
- Petrol bung fitted as standard
- Large nickel-plated clunk
- Single or twin vent configuration
- Size: 27 x 9.3 x 12 cm
- Weight: 225 g
- Can be used with pressurised fuel systems
Tech Specs
- Shipping weight: 0.24 kg (0.53 lbs)
Secured by Stripe
FEATURES
- Comes complete with all hardware
- Includes our one piece clunk with fuel barbs built right on the clunk stem
- Your fuel tubing will not slide off!
- Fuel Tanks can be used with either glo-fuel or gasoline
DETAILS
DU-BRO fuel tanks are designed to be tough! Our fuel tanks will not split or crack from vibration or pressure. In fact, our fuel tanks can be used with pressurised fuel systems! Comes complete with all hardware, including our one piece clunk with fuel barbs built right on the clunk stem. Your fuel tubing will not slide off! DU-BRO fuel tanks can be used with either glo-fuel or gasoline if you purchase the DUB400 gasoline conversion stopper.
Note: #690-692 come with both tubing and fuel stopper for gas and glo fuel.
#795-797 are set up for gas only.
*Tank capacity noted for each tank is approximate and may vary slightly.
**2 & 4 oz tanks do not have the protruding "lip" on the tank. All other sizes do.
| SIZE | HEIGHT | WIDTH | LENGTH | WEIGHT |
| 2 oz | 2 3/4" (69.85 mm) L | (34 grams) | ||
| 4oz | 3 3/4" (95.25mm) L | (41 grams) | ||
| 6oz | 3 7/8" (98.43mm) L | (56 grams) | ||
| 8oz | 4 7/8" (123.83 mm) L | (64 grams) | ||
| 10oz | 4 7/8" (123.83 mm) L | (66 grams) | ||
| 12oz | 5 3/8" (136.53 mm) L | (68 grams) | ||
| 14oz | 5 3/8" (136.53 mm) L | (72 grams) | ||
| 16oz | 5 7/8" (149.23mm) L | (77 grams) | ||
| 20 oz | 7" (177.8 mm) L | (96 grams) | ||
| 24 oz | 7 1/2" (190.5 mm) L | (100 grams) | ||
| 32 oz | 7 3/4" (196.85 mm) L | (160 grams) | ||
| 40oz | 8" (203.2 mm) L | (178 grams) | ||
| 50oz | 8 3/8" (212.73 mm) L | (186 grams) | ||
60oz @6 P.S.I. | 4.46" (113.28mm) H | 4 1/2" (114.3 mm) W 5.090" (129.29mm) W | 8 5/8" (219.08 mm) L | (182 grams) |
80oz @6 P.S.I. | 4.705" (119.51 mm) H | 4.812" (122.2 mm) W 5.27" (133.86 mm) W | ||
100oz @6 P.S.I. | 4.99" (126.75 mm) H | 5 1/4" (133.35 mm) W 5.70" (144.78 mm) W |
Key Info:
- Brand: Dubro
- Part No: DUB796
- Barcode: 011859007966
