FMS 120A ESC for 90mm Viper, 3–8S, XT90 – FMSPRESC037

Brand: FMS

Part No: FMSPRESC037

£119.99 RRP £119.99
Pre-Order

Finance options available at checkout.

Request Price Match Ask a Question Write a Review

Fits These Models (1)

Show all 1 models

Description

The FMS 120A ESC (FMSPRESC037) is a high-current, switch‑mode speed controller for 3–8S LiPo setups. Supplied with an XT90 battery connector, 4.0mm motor connectors and a 300 input cable, it provides an adjustable BEC and multiple programmable parameters to fine‑tune performance and protection.

Key Specifications

  • Model: 120A ESC
  • Continuous current: 120A
  • Peak current: 150A
  • Input: 3–8S LiPo
  • BEC: 5.2V/6V/7.4V adjustable, continuous/peak current of 8A/20A (switch‑mode)
  • Size (LxWxH): 77 x 35 x 19mm
  • Weight: 93g
  • Connectors: XT90 battery; 4.0mm motor connectors
  • Cable: 300 input cable

Programmable Items

  • Brake setting: Enabled / Disabled
  • Battery type: LiPo / NiMH
  • Low voltage protection mode (cut‑off mode): Soft cut‑off (gradually reduce the output power) / Cut‑off (immediately stop the output power)
  • Startup mode: Normal / Soft / Super‑soft (300ms / 1.5s / 3s)
  • Timing: Low / Medium / High (3.75 / 15 / 26.25)

Suggested Compatibility

  • FMS 90mm Viper
Free Shipping

On UK Orders over £100
Happy to Help

Helpful, friendly advice
28 Day Returns

Easy returns process
Secure Payments

Secured by Stripe

Specifications

  • Model: 120A ESC
  • Cont current: 120A
  • Peak current: 150A
  • Input: 3-8S LiPo
  • BEC: 5.2V/6V/7.4V Adjustable, Continuous/Peak Current of 8A/20A (Switch-mode)
  • Size (LxWxH): 77 x 35 x 19mm
  • Weight: 93g

Programmable Items

  • Brake Setting: Enabled / Disabled
  • Battery Type: LiPo / NiMH
  • Low Voltage Protection Mode (Cut-Off Mode): Soft Cut-Off (Gradually reduce the output power) / Cut-Off (Immediately stop the output power)
  • Startup Mode: Normal / Soft / Super-soft (300ms / 1.5s / 3s)
  • Timing: Low / Medium / High (3.75 / 15 / 26.25)



Key Info:
  • Brand: FMS
  • Part No: FMSPRESC037
  • Barcode: 7840853310122
