HSD Jets EVO 13 Ultra Pro Pneumatic Controller

The HSD Jets EVO 13 Ultra Pro Multi-Function Pneumatic Controller (HSDS43010100) brings precise, sequenced control to RC jet pneumatic systems. Designed for undercarriage, gear doors and wheel brakes, it combines robust functionality with an intuitive 0.96-inch OLED display and simultaneous digital readout of gear and brake pressure. Built-in leak protection and automatic low-pressure pump restart help maintain stable system performance, while S.Bus compatibility streamlines integration.

Selectable pressure units (PSI, Bar or kg-cm) and three u/c and gear door programming modes support a wide range of advanced setups. Operating from 6.0 to 7.4V with an operating pressure range of 0 to 150 PSI, the EVO 13 Ultra Pro is a compact, high-precision solution for sophisticated air systems in performance models.

Key Features

• For sequenced control of undercarriage, gear doors and wheel brakes
• Three u/c and gear door programming modes
• 0.96-inch OLED display
• Simultaneous digital display of gear and brake pressure
• Built-in system failure (leak) protection
• Automatic low pressure air pump restart programming
• Select units of pressure: PSI, Bar or kg-cm
• S.Bus compatible

Technical Specifications

• Working voltage: 6.0 to 7.4 V
• Current consumption: 2 A
• Operating pressure range: 0 to 150 PSI
• Air pressure precision: ±1% @ 150 PSI
• Size (L x W x H): 67 x 54 x 29
• Weight: 140 g
• Shipping weight: 0.33 kg / 0.73 lbs
