Kyosho Optima Mid Koswork Edition Kit

The Kyosho Optima Mid Legendary Series – Koswork Edition (K.30622KE) celebrates an icon of 1/10 racing, refreshed for today. Retaining the classic mid-motor belt-drive layout and racy body lines, this special edition adds premium Koswork components for enhanced rigidity, precision and durability while staying faithful to the Optima Mid spirit.

Koswork Edition Includes

• Koswork carbon side plate
• Koswork carbon suspension holders
• Koswork carbon rear camber link mount
• Koswork carbon rear shock tower
• Koswork carbon front shock tower
• Koswork universal drive shafts
• Koswork turnbuckle set HD

Updated to suit modern electronics and motors, the Optima Mid brings a smooth, efficient belt 4WD drivetrain with adjustable tension and refined geometry. It combines nostalgic looks with contemporary tuning potential for track or display.

Features

• Recreation of the classic 4WD racing buggy, updated for modern R/C systems
• Belt-type 4WD for efficient, stable drive on low to high grip
• 48-pitch pinion and 82T spur; supports optional 78T/80T spur gears
• Reinforced slipper clutch to handle powerful brushless motors
• Battery holder accommodates various pack types; hook-and-loop strap included
• New wheels in original Optima Mid design with Turbo Optima tyres
• Reinforced nylon rear wing with three mounting angles
• Blister packaging style evokes the original release
• Wide range of optional parts available
• Gold anodised threaded oil shocks
• FRP front and rear shock stays
• 6061-T6 aluminium, countersunk main chassis
• Moulded resin belt covers with easy-adjust belt tensioner
• Full ball bearings and hex hardware
• Adjustable toe-angle rear hubs
• Updated steering bellcrank with integrated servo saver
• Strengthened suspension arms with stabiliser mounts
• 12 mm hex drive with locking pin
• 2.2" one-piece wheels and clear body with decals to recreate the original look

Technical Data

• Length: 375 mm
• Width: 244 mm
• Height: 142 mm
• Wheelbase: 255 mm
• Tread (F/R): 208 mm
• Weight: approx. 1,600 g (with 7.2V 4000 LiPo)
• Tyres (F/R): Ø82 × 36 mm
• Motor: 540-class (sold separately)
• Gear ratio: 8.28:1

Kit Contents

• Kit chassis
• Tyres
• Wheels (white)
• Clear body
• Wing (white)
• Mask sheet
• Decals
• Hex wrench
• Cross wrench
• Shock wrench
• Grease
• Shock oil

Required for Operation

• 2-channel R/C system
• Servo
• 540 motor
• ESC
• Battery for chassis (7.4V Ni-MH or 7.4V Li-Po)
• Charger for chassis battery
• Transmitter batteries
