Kyosho Mini-Z Buggy MB010VE 2.0 SP Chassis Set

Kyosho Mini-Z Buggy MB010VE 2.0 SP Chassis Set

Brand: Kyosho

Part No: K.32294B

£313.40 ~~RRP £329.89~~

Shadow Stock: Usually ships within 4-5 days

Collect Instore

Request Price Match Ask a Question Write a Review Show Spares and Option Parts

The Kyosho Mini-Z Buggy MB010VE 2.0 SP Chassis Set (K.32294B) delivers compact off-road performance with an 8500KV brushless motor, reinforced drivetrain components and precision ESC control. Supplied with a clear Inferno MP9 TKI body, wheels and tyres, it forms a robust racing platform ready for tuning. The new ESC, co-developed with Scorpion Power System, adds expanded parameters including brake frequency and ESC protection, adjustable via the optional Setup Cable (No.82082) and free software. An FHSS receiver board with a gyro unit is installed, with suggested compatibility with the KT-531P transmitter.

Features & Highlights

MINI-Z Buggy MB-010VE 2.0 chassis set equipped with a brushless motor.
New ESC jointly developed with Scorpion Power System for precise adjustment.
Revised ESC circuit board improves throttle control.
Additional settings include brake frequency and ESC protection.
Settings adjustable via Setup Cable (No.82082, sold separately) and free software.
Full ball bearing specification, as per the current Buggy Series.
Includes previously optional Under Guard and Ball Stud Wrench (MBW033) for increased chassis rigidity.
Wide range of optional parts available for further tuning upgrades.
Drivetrain reinforcement parts (MDW028/MBW034/MBW035) installed as standard.
Supplied with Inferno MP9 TKI clear body, tyres and wheels.
FHSS receiver board with gyro unit; suggested compatibility with KT-531P transmitter.

Specifications

Length: 163 mm
Width: 105 mm
Height: 46 mm
Wheelbase: 115 mm
Tread (F/R): 89 mm / 89 mm
Tyres (F/R): φ37 × 13.5 mm / φ37 × 18.5 mm
Weight: approx. 200 g
Motor: SPEED HOUSE XSPEED 85 (8500KV)

What’s in the Box

Factory-assembled chassis with EVO main unit installed
Pinion gears (15T, 17T, 19T, 21T)
DWS conversion parts and front tread conversion parts
Pinion gear removal tool
Spare wheel nuts
Wheel wrench
Centre shaft for L wheelbase
Wide rear suspension arms for DWS
Long swing shafts (4 pcs.)
Spur gears (27T, 29T, 31T)

Required to Complete

KT-531P transmitter
Paint for body
4 x AAA alkaline or Ni-MH batteries for chassis
4 x AAA alkaline batteries for transmitter (EX-5UR ASF requires 8 x AA alkaline batteries)

Free Shipping

On UK Orders over £100

Happy to Help

Helpful, friendly advice

28 Day Returns

Easy returns process

Secure Payments

Secured by Stripe

MINI-Z Buggy VE 2.0 SP Chassis Set comes equipped with drivetrain reinforcement parts as well as body, wheels and tires! The MINI-Z Buggy MB-010VE 2.0 SP Chassis Set is great for a racing platform. The extreme power generated by an 8500KV brushless motor is transmitted through the robust drivetrain installed with reinforcement parts as standard. In addition to the throttle and brake parameter settings possible with the previous model ESC with Setup Cable (No.82082, sold separately) and free software download, this new circuit board features brake frequency and ESC protection settings. With each parameter setting, you can create a MINI-Z Buggy that fits your driving style perfectly. The receiver is compatible with the KT-531P transmitter; MINI-Z RWD, AWD, FWD and Buggy Readyset users can step into the exciting off-road racing using an on-hand transmitter.

MINI-Z Buggy MB-010VE 2.0 Chassis Set, equipped with brushless motor.
New ESC jointly developed with Scorpion Power System enables precision adjustment of each setting.
Newly developed ESC circuit board dramatically improves throttle control.
Additional settings include brake frequency and ESC protection settings.
New version with additional setting options. Settings can be changed with Setup Cable (No.82082, sold separately) and free software download.
Full bearing specifications, just like the current Buggy Series.
Includes previously optional Under Guard and Ball Stud Wrench (MBW033) for increased chassis rigidity.
Huge range of optional parts is available for tuning upgrades.
Drivetrain reinforcement parts (MDW028/MBW034/MBW035) are installed as standard.
Comes with Inferno MP9 TKI clear body, tires and wheels.
The FHSS type receiver board is compatible with the KT-531P transmitter. Equipped with gyro unit as standard.

Specifications:

Length　163mm
Width　105mm
Height　46mm
Wheelbase　115mm
Tread（Ｆ/Ｒ）　89mm/89mm
Tires（Ｆ/Ｒ） φ37×13.5mm／φ37×18.5mm
Weight　200g approx.
Motor　SPEED HOUSE XSPEED 85 (8500KV)

What's in the Box:

Factory-assembled chassis equipped with EVO main unit installed
Pinion Gears (15T, 17T, 19T, 21T)
DWS conversion parts - Front tread conversion parts
Pinion gear removal tool
Spare wheel nuts
Wheel wrench
Center shaft for L wheelbase
Wide rear suspension arms for DWS
Long swing shaft (4 pcs.)
Spur gears (27T, 29T, 31T)

Required to Complete:

KT531P transmitter
Paint for body
4 x AAA alkaline or Ni-MH batteries for chassis
4 x AAA alkaline batteries for transmitter (EX-5UR ASF requires 8 x AA alkaline batteries)

Key Info:

Brand: Kyosho
Part No: K.32294B
Barcode: 4548565477821
Scale: 1:28
Vehicle Type: Buggy
Power Source: Electric - Brushless
Surface Type: Off Road
Build Level: Unassembled (Kit)
