Maverick Msc-30Bl-Wp Brushless Speed Controller (T-Plug)
Maverick Msc-30Bl-Wp Brushless Speed Controller (T-Plug)
Maverick Msc-30Bl-Wp Brushless Speed Controller (T-Plug)
Maverick Msc-30Bl-Wp Brushless Speed Controller (T-Plug)

Maverick Msc-30Bl-Wp Brushless Speed Controller (T-Plug)

Brand: Maverick

Part No: MV30003

£81.12 RRP £85.39

Shadow Stock: Usually ships within 4-5 days

Collect Instore
#MV30003 - MSC-30BL-WP BRUSHLESS SPEED CONTROLLER (T-PLUG)

Replacement Brushless ESC for the Strada Red series of cars Can also be used to upgrade the standard Strada when used in conjunction with a Brushless Motor: #MV22602 - MM - 22BL 3215KV Brushless Motor MSC-30BL-WP BRUSHLESS SPEED CONTROLLER Features

  • Water-resistant* and dust-proof. The ESC has been designed to work in wet conditions.
  • 2-3S Capable (for 3S you must change the standard 5V cooling fan to a 12V cooling fan, or supply the 5V cooling fan from the receiver 5-6V);
  • Compatible with sensorless brushless motor.
  • 2 running modes (“Forward with brake” mode, “Forward/Backward with brake” mode).
  • Proportional ABS brake function with 4 steps of maximum brake force adjustment, 8 steps of drag-brake force adjustment.
  • 4 Punch modes from “Soft” to “Very aggressive” to be suitable for different chassis, tires and tracks.
  • Multiple protection features: Low voltage cut-off protection for Lipo or NiMH battery / Over-heat protection /Throttle signal loss protection / Motor blocked protection.
  • Easily programmed with the “SET” button
*Please remove the cooling fan when running the ESC very wet conditions. *After running the ESC in wet conditions, please clean and dry it to avoid the oxidation to copper connectors Specification
  • Continuous Current: 45A
  • Burst Current: 220A
  • Resistance: 0.0012 ohm
  • Application: 1/10 scale on-road and off-road
  • Motor Limit:
  • 2S LiPo or 6 cells NiMH - On-road: ≥9T, Off-road: ≥12T, 3650 size motor
  • 3S LiPo or 9 cells NiMH - On-road: ≥12T, Off-road: ≥18T, 3650 size motor
  • Battery: 4-9 Cells NiMH or 2-3S Lipo**
  • Built-in BEC: 6V/2A
  • Program Port: Multiplexed with cooling fan port
  • Motor Type: Sensorless Brushless
  • Dimension: 48.5 x 38 x 32mm
  • Weight (with wires): 90g
**1) For 4-6 cells NiMH or 2S Lipo: You needn't change the 5V cooling fan on the ESC; **2) For 7-9 cells NiMH or 3S Lipo: You must change the original 5V cooling fan to 12V cooling fan, or supply the 5V cooling fan from the receiver (5-6V);
