Power HD T70 HV Alloy Case MG HV Servo - 70kg - 0.12s

The Power HD T70-BHV (HD-T70-BHV) is a high-voltage, alloy-case metal gear servo engineered for demanding control tasks. A brushless motor and dual ball bearings deliver smooth, consistent performance inside a compact 40.7 × 20.5 × 38.7 mm case weighing just 83 g.

At 8.4V the T70-BHV develops up to 70.0 kg-cm torque with a swift 0.12 s transit speed, with strong performance maintained across the 6.0–8.4V operating range. Its steel and aluminium gear train, 1520 μs / 333 Hz working frequency and −20℃ to 60℃ operating temperature range support reliable operation in varied conditions. Suggested compatibility includes high-torque RC applications where HV servos and robust metal gears are preferred.

Key Specifications

• Torque (6.0V): 55.0 kg-cm / 763.8 oz/in
• Torque (7.4V): 60.0 kg-cm / 833.2 oz/in
• Torque (8.4V): 70.0 kg-cm / 972.1 oz/in
• Speed: 0.160 s (6.0V) | 0.140 s (7.4V)
• Speed: 0.120 s (8.4V)
• Operating voltage: 6.0–8.4V DC
• Weight: 83 g (2.93 oz)
• Bearing type: Ball bearing × 2
• Motor type: Brushless motor
• Gear type: Steel & aluminium
• Operating temperature: −20℃ to 60℃
• Working frequency: 1520 μs / 333 Hz
• Size: 40.7 × 20.5 × 38.7 mm (1.60 × 0.81 × 1.52 in)
