Savox SB3292SG HV Brushless CNC Servo - 65Kg 0.13s

The Savox SB3292SG HV Brushless CNC Servo delivers serious holding power and responsive control for demanding RC applications. Rated at 65 kg-cm torque and 0.13 s/60 at 7.4V, with increased output of 75 kg-cm and 0.110 s/60 at 8.4V, it combines high voltage performance with smooth, brushless precision. A CNC-machined full aluminium case enhances rigidity and heat dissipation, while unique steel gears and triple ball bearings support durability and consistent operation under load.

Engineered with a 25-tooth output spline for broad horn choice and precise linkage setup, this servo is built to handle heavy-duty steering or throttle/brake duties where accuracy and strength matter. The SB3292SG (part number SAV-SB3290SG) brings together robust materials and efficient internals to provide dependable performance run after run.

Key Specifications

• Dimensions (mm): 40.3 x 20.2 x 37.6
• Weight: 72 g
• Speed @ 7.4V (sec/60): 0.13
• Torque @ 7.4V (kg-cm): 65
• Speed @ 8.4V (sec/60): 0.110
• Torque @ 8.4V (kg-cm): 75
• Gears: Unique Steel
• Bearings: 3BB
• Case: Full Aluminium
• Servo Horn Spline: 25-tooth

Design Highlights

• HV brushless architecture for responsive, efficient control
• CNC full aluminium case for strength and thermal stability
• Triple ball bearings for smooth, supported output
• Steel geartrain for long-lasting, high-load reliability

Notes

• New Savox and Plus "+" models feature a Soft Start Mode and Sanwa SSR compatibility.
• A Performance Radar view helps compare key metrics such as speed, torque and precision across Savox servo models.
