Stinger Engines 35cc Rear Exhaust Petrol Engine RCGF35RE
Brand: Stinger Engines
Part No: RCGF35RE
Expected Mon 16 Nov
Request Stock NotificationFits These Models (1)
Show all 1 models
Customers Also Buy
Popular with customers who buy products like the Stinger Engines 35cc Single Cylinder Rear Exhaust 2-Stroke Petrol Engine
Description
The Stinger Engines 35cc Single Cylinder Rear Exhaust 2-Stroke Petrol Engine (RCGF35RE) is a single-cylinder petrol engine for radio-controlled aircraft. It uses a two-stroke design with a rear exhaust arrangement and 35cc displacement, providing an alternative to traditional glow-powered model aircraft engines.
The engine has been re-engineered with revised internal parts, a tougher crank system, bearings and an aluminium case. Its petrol operation uses a 30:1 petrol-to-oil mixture, while the supplied NGK CM6 spark plug and electronic CDI unit provide the ignition components needed for the engine system. The stated static thrust is 19.9lb, and the engine weight of 1,145g includes the muffler and CDI unit.
RCGF has developed the Stinger range for model aircraft use, with this version intended for experienced users and outdoor operation at a designated model flying site. The package includes the engine, ignition and mounting-related components, along with a muffler and instruction manual. A suitable propeller and ignition battery are required to complete the installation.
What's Included
- Stinger 35cc single-cylinder engine
- Electronic CDI unit
- NGK CM6 spark plug
- Muffler
- Gasket and bolt set
- Throttle arm extension
- Engine stand-off set
- Instruction manual
Required to Complete
- 19x8, 20x8 or 20x10-inch propeller
- 6–8.4V NiMH, 6.6V LiFe or 7.4V LiPo ignition battery
Specifications
- Displacement: 35cc
- Weight including muffler and CDI: 1,145g
- Fuel: Petrol
- Petrol-to-oil mixture: 30:1
- Static thrust: 19.9lb
- Recommended spark plug: NGK CM6
Secured by Stripe
Stinger Engines 35cc Single Cylinder Rear Exhaust 2-Stroke Petrol Engine Manuals & Guides
Manuals & Guides
Specifications
One of the strongest and most powerful engines in its class RCGF s compact Stinger 35cc RE has been built to offer years of trouble-free service. Re-designed and re-engineered, Stinger engines incorporate a more robust metallurgy in their parts and a tougher crank system allied to exceptionally high quality bearings. Add this to a case that's manufactured from a tailored no-compromise aluminium alloy and the result is not only an impressive power output but a stronger, more attractive product all round.
Having stood the test of time by providing solid, reliable and powerful petrol engines for well over a decade, greater numbers of R/C pilots are turning to Stinger engines for their aircraft, partly due to the obvious fuel efficiency of the type but also due to the economy of scale that these particular purpose-designed two-strokes offer, especially as an alternative to traditional glow power. If you love engines, as many do, Stinger is the way to go.
Specification:
| Displacement (cc): | 35 |
| Bore (mm): | 39 |
| Stroke (mm): | 30 |
| Weight (g): | 1145 |
| Fuel: | Petrol |
| Petrol / Oil mix: | 30:1 |
| Static thrust (lb): | 19.9 |
| Spark plug: | NGK CM6 |
Stinger Engines 35cc Single Cylinder Rear Exhaust 2-Stroke Petrol Engine Tech Specs:
Stinger Engines 35cc Single Cylinder Rear Exhaust 2-Stroke Petrol Engine Key Features:
- One of the strongest and most powerful engines in its class RCGF s compact Stinger 35cc RE has been built to offer years of trouble-free service. Re-designed and re-engineered, Stinger engines incorporate a more robust metallurgy in their parts and a tougher crank system allied to exceptionally high quality bearings. Add this to a case that's manufactured from a tailored no-compromise aluminium alloy and the result is not only an impressive power output but a stronger, more attractive product all round.
Having stood the test of time by providing solid, reliable and powerful petrol engines for well over a decade, greater numbers of R/C pilots are turning to Stinger engines for their aircraft, partly due to the obvious fuel efficiency of the type but also due to the economy of scale that these particular purpose-designed two-strokes offer, especially as an alternative to traditional glow power. If you love engines, as many do, Stinger is the way to go.
Specification:
Displacement (cc): 35 Bore (mm): 39 Stroke (mm): 30 Weight (g): 1145 Fuel: Petrol Petrol / Oil mix: 30:1 Static thrust (lb): 19.9 Spark plug: NGK CM6
What's in the Box:
- 1x Stinger 35cc Single.
- 1x Electronic CDI unit.
- 1x Spark plug.
- 1x Muffler.
- 1x Gasket and bolt set.
- 1x Throttle arm extension.
- 1x Engine stand-off set.
- 1x Comprehensive instruction manual.
Needed to Complete:
- 1x 19x8, 20x8 or 20x10" propeller.
- 1x Ignition battery (6 – 8.4V NiMH, 6.6V LiFe or 7.4V LiPo).
Stinger Engines 35cc Single Cylinder Rear Exhaust 2-Stroke Petrol Engine Tech Specs:
- Weight: 1145 (inc. muffler and CDI)g / 40.39oz
- Shipping Weight: 1.75kg / 3.86lbs
- Application: Aircraft
- Displacement: 35mm3
- Cylinder Bore: 39mm
- Experience Level: Experienced
- Recommended Usage Environment: Outdoors / designated model flying site
- Material: Aluminium
Key Info:
- Brand: Stinger Engines
- Part No: RCGF35RE
- Barcode: 5051121256161
- Fitment: Option Part
- Format: Petrol
