Tamiya TBLE-05SR ESC for Tamiya Brushless Motors (Sensored)
Brand: Tamiya
Part No: HC-45071
£89.99
RRP £99.99
Out Of Stock
Request Stock NotificationThe Tamiya TBLE-05SR (HC-45071) is a sensored brushless electronic speed controller designed specifically for use with Tamiya brushless motors (sensored). It delivers robust performance and easier setup, with the same maximum RPM capability as the TBLE-04SR, plus improved heat management and installation convenience.
Key Features
- Dedicated brushless motor connector for efficient power delivery
- Motor connectors can be connected directly to the motor
- Parallelised FET layout enhances high current resistance; maximum RPM matches the TBLE-04SR
- Black-anodised aluminium case acts as a heat sink for improved cooling; accepts a 25mm square cooling fan
- Receiver switch with screw-attached case protects cables and increases rigidity
- Set button located on the receiver switch for easier setup changes (moved from the ESC on TBLE-04SR)
- User-tunable settings for battery cut-off, reverse, brake, soft start and neutral brake; status verified via three LEDs and audible tones
- Overheat and overload protection functions help safeguard your equipment
- Includes 270mm sensor cable
Specifications
- Maximum continuous current: 90A
- Input voltage: 6.6V–7.2V
- Weight: 76g (including cables)
- Dimensions (approx.): 42.5 x 33.5 x 24.5mm (with fan: 42.5 x 33.5 x 33.5mm)
Suggested Compatibility
- Tamiya Brushless Motor 02 (Sensored) 15.5T, Item 54612
Secure Payments
Secured by Stripe
This ESC is designed only for use with Tamiya Brushless Motors (Sensored). Please kindly note that we plan to discontinue Item 45070 Tamiya Brushless Electronic Speed Controller 04SR (Sensored).
About the Item
- Dedicated brushless motor connector enables more efficient power supply
- Motor connectors can be directly connected to motor
- The FET (Field Effect Transistor) layout features parallelization to reinforce high current resistance. The maximum RPM is the same level as the TBLE-04SR
- The black-anodized aluminium case works as heat sink to ensure improved heat dissipation, and 25mm square cooling fan can be attached (*the TBLE-04SR had plastic case)
- Features a receiver switch with screw-attached switch case which protects cables and reinforces case rigidity
- The TBLE-05SR has a set button on the receiver switch for easier setup changes while the TBLE-04SR had it on the ESC
- Settings such as battery cut-off, reverse, brake, soft start and neutral brake can be changed by the set button and can be checked by three LED lights and sounds
- Features overheat and overload protection functions to help ensure that your equipment avoids damage
- Compatible with Item 54612 Tamiya Brushless Motor 02 (Sensored) 15.5T
- Includes 270mm sensor cable (the same cable as the one included in Item 45070)
- Maximum continuous current: 90A
- Input voltage: 6.6V - 7.2V
- Weight: 76g (including cables)
- Dimensions (approximate): 42.5 x 33.5 x 24.5mm (with fan: 42.5 x 33.5 x 33.5mm)
Key Info:
- Brand: Tamiya
- Part No: HC-45071
- Barcode: 4950344450718
- Motor Type: Brushless
- LiPo Compatible: Yes
