Vanquish Currie F10 Portal Aluminium Front Axle Black

The Vanquish Products Currie F10 Aluminium Front Axle Housing (Black), part number SCH-VPS08615 (VPS08615), is a premium, USA‑machined upgrade for F10 portal front axles. Built to the same outside dimensions as the moulded F10 housing, it maximises clearance while allowing you to utilise the original F10 components. Precision‑cut from high‑quality domestically produced aluminium on true 5‑axis CNC machines, it delivers excellent strength, accuracy and longevity for demanding RC crawling.

Geometry is optimised with a 20° caster angle and built‑in steering bump stops set at 49°. A full‑width axle truss ties into the upper link and panhard mount for rigidity, while the tucked C‑hub design moves the lower portion of the C up inside the knuckle for class‑leading knuckle clearance.

Features

• Machined in the USA
• Made from high‑quality, domestically produced aluminium
• Suggested compatibility: replacement for F10 Front Portal Axle housing
• 20° caster angle
• Built‑in steering bump stops at 49°
• Full axle truss tied into upper link and panhard mount spanning the full axle width
• Tucked "C" design for added clearance at the steering knuckle

What’s Included

• 1x F10 Front axle housing

Compatibility and Notes

• Suggested compatibility: VS4‑10 Phoenix Portal Kit (F10 portals) and VPS08600 F10 Front Axle Set
• Replaces plastic axle housing from VPS09007 and VPS08600
• Reuses original F10 components: bearings, hardware, third member, bearing retainers, gears, knuckles, axle shafts
• Not compatible with brass tubes used in moulded housings
• For assembly guidance, refer to the VPS09007 or VPS08600 instruction manuals
