XRay XT2D 28 Dirt Edition 2WD Stadium Truck XR320211

XRAY XT2'28 All-new Features:

• All-new 2.5mm chassis with optimized flex engineered for maximum traction & control
• Widened rear chassis section increases stability
• All-new Flat Chassis Brace provides tunable flex control
• Longer side guards extend flex control & add new fan mount position
• Redesigned RF (C) suspension holder integrates with Flat Chassis Brace
• All-new 3G gearbox updated for the lower chassis brace
• Lowered motor mount reduces CG
• New lighter differential outdrives reduce rotational mass for faster acceleration, sharper braking, and improved drivetrain efficiency
• Aluminum rear roll center holder adds third roll center position & clearance for rear anti-roll bar collar
• Solid front suspension arms – medium
• Solid rear suspension arms – medium
• 3.5mm turnbuckles increase durability & rigidity
• 5.4mm ball ends improve strength & reliability
• 5.4mm composite ball joints ensure smooth, consistent suspension movement
• All-new front & rear carbon shock towers with lower mounting geometry
• New front & rear springs combatible with XB2
• Shorter shock bodies & shafts reduce mass & lower CG
• +2mm shock ball joints increase droop adjustment range
• -2mm & -4mm spring collars expand ride height adjustment options
• New low-profile body lowers CG & improves handling
• Soft composite front anti-roll bar mounting plate for increased reliability

XT2 Concept

The XT2 is distinctively XRAY – a premium, professional, high-competition R/C stadium truck for the most demanding of racers; developed with attention to the smallest details and backed by leading service & support…a luxury masterpiece.

Uni-Platform™

The XT2 platform works at the highest competition level in any track condition.

Whether it be super-low-traction dusty tracks, medium-traction, super-high-traction carpet or astro turf; there is a XT2 that will handle flawlessly for you in any condition.

The XT2 is available in two different editions – Carpet or Dirt; each specifically built for particular track conditions. Both editions are built on the same platform with full compatibility and interchangeable parts and the XT2 also shares many components with the XB2.

Chassis

A completely redesigned 2.5mm one-piece chassis with a wider rear section improves traction and stability on all surfaces.

The wider rear geometry enhances flex characteristics, resulting in more consistent handling and improved overall balance.

The chassis plate is CNC-machined from high-quality 2.5mm Swiss 7075 T6 aluminum to maximize stability, durability, and drivability while helping to lower the center of gravity.

The centerline cut-out is now connected to the electronics plate milling, allowing the sensor cable to be routed underneath the battery for a cleaner electronics installation.

Additional milling in strategic areas refines the flex characteristics and improves handling response, allowing the chassis to deliver more precise and consistent performance.

Flat Chassis Brace

The bottom aluminum Flat Chassis Brace is an all-new concept carried over from the popular XB2 platform, where it has proven highly successful and now adopted on the XT2.
This innovative system allows the chassis flex to be easily adjusted to match the traction level of any track condition.

This brace is mounted directly onto the chassis and is connected with the rear gearbox and C suspension holder.

The Flat Chassis Brace is significantly lower, lighter, and allows for extremely simple yet powerful flex adjustments.

The flex of the brace is adjustable by adding or removing screws to create the perfect flex characteristics for any conditions.

Side Braces

Redesigned longer side braces match the new chassis design.  The longer braces extend the longitudinal chassis flex control to improve consistency on the track.
The left side brace also allows for a fan to be mounted directly to the brace for enhanced motor cooling.

The side braces support the one-piece chassis design and connect with the front end. The flex of the side braces was optimized to improve front stability & rear traction. The braces feature several mounting holes for the battery holders to provide sufficient range of battery position choices.

The side braces are available in two different hardness alternatives. Both Dirt and Carpet edition comes with medium stiffness and optional Graphite braces are suggested for extra high traction conditions.

Suspension Holders

New design of the rear-front RF suspension holder (C) integrates with the Flat Chassis Brace to create a solid assembly for increased stability.
The rear-rear RR (D) suspension holder geometry creates 3.0 degrees of inboard rear toe for stability in all track conditions, and increased suspension support both in and out of the corner.

The aluminum suspension holders feature Integrated Suspension Settings (I.S.S.™) for quick & easy suspension geometry set-up.

Machined from premium Swiss 7075 T6 aluminum and black coated.

The suspension holders are universal for both Dirt and Carpet editions.

3G Gearbox

Updated 3G Gearbox integrates with the lower Flat Chassis Brace. The weight bias of the 3G transmission creates a balance between steering and stability that is well suited for a wide variety of track conditions on dirt, clay, turf or carpet.

The 3G Gearbox is included in both XT2C and XT2D, with the universal design allowing easy & fast changes between 3G and optional 5G without changing the chassis.

Super-narrow, ultra-low CG gearboxes (LCG) features quick & easy diff access. The narrower design of the gearbox reduces weight and moves all parts closer to the chassis centerline.

Gear Differential

The Gear diff in the Carpet edition was redesigned to allow for unified drive shafts length for the Ball Diff and Gear Diff alternatives. The diff case, diff cover and diff outdrives were updated.

The gear diff comes now with steel satellite gears for improved efficiency and increased lifespan.

The gear differential is suggested for medium to high traction conditions as it increases on-power steering and is beneficial on all carpet tracks.

Motor Mount

Redesigned and unified motor mount for 3G Gearbox takes advantage of the additional chassis clearance and lowers the motor position for lower CG.

The super lightweight motor mounts are machined from Swiss 7075 T6.

The molded composite gear protector prevents contact between the spur gear and the body. Moulded from strong, lightweight material, the cover helps to protect the body shell and spur gear, and it allows the body to be mounted lower without interference.

Rear Roll Center Holder

New aluminum Rear Roll Center Holder is included in both Carpet & Dirt kit. Its centering milled area for the anti-roll bar collar eliminates play and improves the precision of the anti-roll bar movement.

The new holder also adds an extra middle pivot ball mounting position for additional roll center tuning. The aluminum holder increases strength & reliability over the previous composite part.

Suspension Arms

The solid front and rear suspension arms accommodate the anti-roll bar system and are molded from medium hardness mixture suitable for all standard track conditions.

The rear arms feature two additional mounting holes to match the updated new shock tower geometry.The solid arm design provides a responsive feel while maintaining enough compliance for extreme durability.

The exclusive composite mixtures used for the suspension arms offer the perfect balance between reliability and performance.

Heavy Duty Turnbuckles

All-new 3.5mm Heavy Duty Turnbuckles together with the new 5.8mm Heavy Duty Ball Joints and Ball Ends ensure super strong and more reliable steering & camber links. The new composite ball joint design reduces bind for smooth suspension and steering movement.

The ball joints increased to 5.4mm instead of the previous 4.9mm. There are two different ball joint shapes: one straight and one curved for improved clearance around the front spring and wheel. The ball joints are slightly longer so the turnbuckle thread deeper in the ball joint to improve reliability and prevent deformation of the plastic at the weakest point at the end of the turnbuckle thread.

The steel turnbuckles increased from 3.0mm to 3.5mm to increase durability.

The new 5.4mm ball ends’ height was increased by 1.0mm to improve the range of motion of the joint. The complete 5.4mm assembly is smoother and more reliable.

Shock Towers

Front and rear carbon shock towers are updated with lower geometry. Lowering the shocks increases stability, cornering speed and makes the handling feel more precise. Thanks to the chassis design, the car’s traction has improved, and the lower shocks help to further improve the handling of the car.

Both front & rear shock towers compliment the big bore shocks.

The extra strong front shock tower is mounted forward for the needed clearance to install the shocks behind the tower for maximum protection in a crash.

Front & rear shock towers are machined from premium-grade carbon material that is lightweight & strong, with multiple shock adjustment positions.

Big Bore Shocks

The big bore 13.2mm shock absorber length was shortened to provide proper suspension travel with the new shock tower geometry. The shock body and shock shaft were shortened to produce the necessary compression and extension range of motion.

The big-bore 13.2mm shocks improve handling, landing, and bump absorption. The X-rings provide smooth operation & dust resistance. Two different piston thicknesses are included in the kit for tuning along with piston blanks for additional tuning possibilities.

The shock absorbers are universal for both Dirt and Carpet edition.

Shock Adjustments

The XT2C & XT2D feature a -2mm lower shock spring collar for front and -4mm for rear to reach lower ride height settings needed on smooth high traction surfaces. The ball joints are in both kits +2mm for perfect balance between droop and upstop travel.

Shock Springs

2-dot front and rear springs are now included in both Carpet & Dirt kits to improve out-of-the-box performance on most tracks.
The shorter springs match the new lowered shock tower geometry while maintaining proper suspension function.

A range of shorter springs in multiple hardness options is available for precise fine tuning to suit different track conditions.

Body & Wing

The updated body for the XT2C & XT2D is redesigned to match the shorter shocks and lower shock tower geometry.

This allowed the body to be mounted lower on the chassis, resulting in a lower center of gravity and improved driving dynamics.

To accommodate the lower body position, the mounting points were revised, and both the front and rear sections, along with the trimming lines, were updated for a precise fit.

The high-performance, low-profile aerodynamic body was designed by XRAY to perfectly fit the XT2 and work in most track conditions. The body is made from high-quality, premium Lexan™ material.

The effective rear wing was designed to work perfectly with the XRAY XT2 body. Made from strong Lexan™ material; the wing is supported on the wing mounts by extra flat shims to better support and extend the life of the wing.

Anti-roll Bars

The front anti-roll bar mounting plate is molded from a soft composite material for increased reliability and perfect integration with the front upper deck.The anti-roll bar system improves cornering performance and makes the XT2 easier to control and more consistent across all track conditions.

The kit comes with 1.6mm anti-roll bar, optional anti-roll bars for fine tuning are available.

Battery Holder

The redesigned side braces allow mounting the battery holders in an extra forward position to move the battery weight as far forward as possible. This additional weight balance alternative expands the weight balance adjustment range to help achieve the best performance on any track condition.

Tweak-free fully adjustable battery holder is integrated into the side guards allowing easy and fast battery position adjustments, as well as simple battery installation through the smart quick-release system.

The battery pack can be easily moved front/rear to adjust the balance of the car.

The height of the battery backstop is adjustable for different battery sizes.

The battery holder is mounted to the chassis through one connecting screw on each side brace to eliminate any effect on chassis flex.

Extra forward battery position to move weight as far forward as possible.

Front End

The front end of the XT2 was specifically designed to be unified for both Carpet & Dirt versions.

Front Upper Deck

Bridge style upper deck helps to optimize flex from side to side and front to rear while also providing clearance for the steering system. The upper allows mounting the shock absorbers behind the shock tower for better protection in a crash

Steering System

Steering arms, Ackermann plate and the servo arm were reconfigured for more precise steering feel. Thanks to the upper deck design, the steering system also has more space to achieve the improved steering performance. To integrate with the one-piece chassis, the steering post was updated as well.

Steering Blocks

To improve the reliability and strength, the steering blocks are molded from a medium hardness composite mixture that is suitable for most track conditions. The medium compound significantly improves the reliability to enable finishing a race after significant crashes or impacts.

Both Carpet and Dirt editions now feature 3 dot steering block extensions better suited for all track conditions. These extensions create a more linear steering that improves control in all conditions.

There are four different steering blocks available – medium (included), hard (option), graphite (option) and aluminum (option) – which can be used to fine tune steering response for various track conditions.

Read more >

Caster Blocks

For maximum reliability and strength, the caster blocks are moulded from a medium hardness composite mixture suitable for most track conditions.Just like the included steering blocks, the medium compound significantly improves the reliability and ensures finish a race even after a punishing crash.

The caster blocks are very lightweight, yet their construction makes them very stiff & rigid. The caster can be adjusted with values 0°, 2.5° or 5° by using included caster bushings.

There are four different caster blocks available – medium (included), hard (option), graphite (option) and aluminum (option), each one suitable for different track conditions.

Front Roll Center

The front roll center holder features the two most widely used roll center positions that are suitable for all track conditions. The roll center block connects to the one-piece chassis and bridge upper deck to form a strong front structure.

The front roll center holder is universal for both Carpet and Dirt Editions.

Arm Mount

The arm mount is an important part of the suspension, connecting the lower arms to the chassis plate. The included composite mount has a 0° kick-up angle, resulting in overall kick-up matching the integrated chassis kick-up of 22°.

Optional aluminum and brass arm mounts are available for weight balance or kick-up adjustment. The aluminum arm mount also includes a provision for a 10g Tungsten Weight for additional weight balance choices.

Shock Pistons

The piston choices were chosen for ideal fit and dampening in the new big bore shock bodies. The 2-hole pistons (1.6 and 1.8mm) are included in 2.0mm or 2.5mm thickness alternatives. In addition, two sets of blank pistons in both thickness alternatives are included for individual custom modification.  All pistons are made from Delrin and are molded using ultra-high precision moulds.

Rear Uprights

The rear uprights with low roll center positions provide increased stability with less collapse of the suspension in high-speed corners.

To improve the reliability and strength, the uprights are moulded from medium hardness composite mixture that is suitable for most track conditions.

Rear uprights feature aluminum roll center mounts with multiple upper roll center positions.

The upper roll center is adjusted at the camber linkage via shims (up/down & in/out), while the lower roll center is adjustable via eccentric inserts for 9 different positions (up/down & in/out).

The multi-function uprights have the upper roll center position in the middle of the axis of the driveshaft joint to help generate more traction and increase stability.

There are four different uprights available: medium (included) hard (optional), graphite (optional), and aluminum (optional), each suitable for particular track conditions.

Ball Differential

Dirt Edition only.

The narrower LCG design fits the narrow gear box and includes all the improvements learned from extensive testing of previous versions for smoother differential action to increase traction.
The redesigned ball differential offers improved performance, durability, and easier maintenance. The externally adjustable ball differential is machined from HUDY Spring Steel™ and is additionally hardened for extra durability and a longer lifespan. A high-quality carbide thrust bearing and carbide balls are included for ultra-smooth operation. The outdrive adapters are designed for use with 2.5mm pin drive shafts.
The ball differential included in the Dirt edition as the suggested choice for most dirt tracks and for bumpy astro tracks.

Drive Shafts

To simplify the spare parts compatibility, the required drive shafts length is unified between the Gear Diff and Ball Diff. Thanks to the gear diff design, the 97mm long drive shafts now fit both differentials.

Manufactured from world-renowned HUDY Spring Steel™ the drive shafts feature 2.5mm drive pins for maximum drivetrain efficiency. The drive shafts are some of the thinnest yet most durable drive shafts used in electric off-road cars. Treated with a proprietary hardening process, the drive shafts provide unbeatable lifespan and reliability.

Easy Diff Access

The LCG gear box features super easy access to the differential. Both XT2D and XT2C trucks benefit from the super easy diff access by removing only 6 screws.
The LCG gearboxes incorporate all the finest details and craftsmanship. All parts fit together perfectly, and the super-easy access to the rear differential will be appreciated by every racer. The durable gear box houses the differential with all the transmission components and serves as the mounting point for the rear roll center holder, motor plate, and rear shock tower.

Diff Height Adjustment

The gear box features differential height adjustment. There are 6 height adjustment positions available using the included eccentric bushings. The ideal position will vary depending on the track conditions, ride height and the size of the tires used.

Gear Box

The super-narrow, ultra-low CG gear box (LCG) features quick & easy diff access. The narrower design of the gear box reduces weight and moves all parts closer to the chassis centerline.

Gear box – for front motor position - keeps more weight over the front axle for improved steering and corner speed on high grip surfaces. Included in the Carpet and Dirt edition.

Slipper Clutch

Power from the motor is transferred to the drivetrain via an externally adjustable slipper clutch for quick & easy tuning.

The slipper clutch components accommodate the LCG gear boxes.

The lightweight slipper plates are machined from premium Swiss 7075 T6 and additionally hardened before a final black surface treatment. The plates have a machined relief which decreases the friction surface to assist with clutch slip adjustment. With this plate design, pressure is focused on the circumference of the clutch pads for increased efficiency.

The slipper pads are made from ultra-efficient SLS material with very-high slip efficiency, thus allowing very precise slip adjustment.

There are two different slipper clutch designs available. The 3-pad slipper assembly is included in both Carpet and Dirt edition trucks for its slippage characteristics matching the needs of most track conditions. The optional 2 pad configurate is available for times when smoother acceleration is needed in lower grip situations.

Motor Plate & Spur Gear Protector

The motor mount plate is redesigned to fit the LCG gear box design and accommodate the updated spur gear protector.

The super lightweight motor mount is machined from Swiss 7075 T6 aluminum.

The molded composite gear protector prevents contact between the spur gear and the body. Moulded from strong, lightweight material, the cover helps to protect the body shell and spur gear.

The motor plate is universal for both Dirt and Carpet edition.

Motor Cooling

The optional cooling fan is mounted via a specially designed composite holder that is mounted only through one screw and a centering pin to minimize vibrations and increases fan lifespan.

There are two different mounting alternatives depending on the battery placement; either behind the motor on the side or in front of the motor in the center of the chassis.

Multi-Adjustable Rear Suspension

The rear suspension features adjustable rear-upright design, longer CVD drive shafts and longer, rear camber link. The adjustable system offers a vast range of roll-center tuning adjustments for different track conditions.

Spur Gear

Precision-molded spur gears are made from XRAY's exclusive secret blend of composite material, allowing the gear to run true yet be robust enough to handle high-performance brushless motors. The spur gears are designed to have the lowest possible weight while staying strong and light. Each gear is stamped with the tooth number for easy identification.

The XT2 is equipped with an 78T spur gear which suits the majority of tracks. For additional tuning, optional 75T and 81T spur gears are available.

Wheel Hubs

The XT2 comes equipped with offset hexes to perfectly match the width of the truck.

Ultra-lightweight 12mm wheel hex-drive hubs are CNC-machined from Swiss 7075 T6 black-coated aluminum. These ultra-true hex hubs have a clamping design to ensure ultra-solid mounting of the wheel’s hub.

To adjust track-width, optional offset wheel hex-drive hubs are available.

Wheelbase & Weight Balance Adjustment

Outer suspension pins holding the front caster block and rear uprights feature wheelbase shims for quick & easy wheelbase and weight balance adjustment. Using included shims in rear and in front, both front and rear blocks can be moved forward or rearward to adjust weight balance depending on track condition.

By moving the arms to the front, the balance & weight of the truck are transferred more to the rear; recommended for medium- and high-traction conditions. By moving the arms to the rear, the balance & weight of the truck transfer moreforward.

Body Mounts

Beefy 6mm thick body posts are made from special composite material that provides maximum strength but sufficient flex to reduce body post breakage in hard crashes or if the XT2 flips over. The body supports are rounded to have a better fit and provide better support to the truck body.

For ultimate tuning and adjustment, XRAY offers optional body height adjustable body posts for independent front & rear body height adjustment by +1mm or +2mm.

Chassis Balance

Chassis design focuses on balanced weight distribution and weight transfer. The chassis features pre-drilled holes for additional balance weights. Centerline holes are pre-drilled for easy balancing with the HUDY Chassis Balancing Tool #107880.

Ball-Bearings

The XT2 features greased ball-bearings for the front steering blocks & rear uprights to increase lifespan in dusty conditions. The remaining bearings are degreased and oiled with AeroShell® Fluid 12 for maximum smoothness and longer life.

A full set of 22 high-speed ball-bearings are used throughout the drivetrain to ensure maximum efficiency.

Silicone Oils

HUDY Exclusive Silicone Oils are manufactured in Europe and each batch is laboratory tested and calibrated to ensure the highest possible consistency and quality from batch to batch. Based on the industry-standard cSt rating, the new line of oils will be easy to identify, adjust, and feel.

When following any set-up sheets by XRAY or XRAY team drivers, you can be sure that the oils you will get for your car are exactly same as those used by the factory racing team, thus ensuring very exacting set-ups and handling.

HUDY Chem Series.

Graphite Grease

The XT2 includes premium HUDY Graphite Grease which is a high-performance, advanced-technology semi-fluid lubricant which incorporates both extreme pressure additives and finely-dispersed graphite for load carrying. It is intended primarily for the lubrication of rotating parts and loaded gears. In addition to providing outstanding load carrying, it is formulated to have excellent adhesion and resistance to "fling-off" under extreme conditions. The grease reduces wear and increases parts life. HUDY Graphite Grease #106210.

Adjustment Possibilities

The extensive range of adjustment possibilities include: caster, camber, toe, kick-up, anti-squat, ride height, downstops, track-width, lower roll center, upper roll center, roll center position, bump steer, wheelbase, Ackermann, adjustable shocks, adjustable rear diff, adjustable slipper clutch, and adjustable XRAY Multi-Flex™.

Set-up Book

The XT2 is one of the most adjustable electric 2WD stadium trucks in the world. Whether you are a hardcore racing enthusiast or a club-level sportsman, you can very easily adjust the XT2 to suit your racing style, track type, and track conditions.

To fully understand the set-up possibilities, we recommend the legendary HUDY Set-up Book: loaded with over 40 pages of high-quality pictures and easy-to-understand RC car set-up explanations. Whether you are a novice driver or an experienced racer, you can easily learn many set-up tips & tricks and improve your set-up skills: ultimately translating into improved racing performance with your XT2. The HUDY Set-up Book is available for download exclusively at  www.hudy.net

• Brand: XRay
• Part No: XR320211
• Barcode: 8581703202110
• Scale: 1:10
• Power Source: Electric - No Motor
• Surface Type: Off Road
• Vehicle Type: Truggy
• Build Level: Unassembled (Kit)
