Description
The ZTW Ubec 12A (part number ZTW300300010) is a switch mode UBEC, a battery elimination circuit that supplies regulated power to the servos and receiver in a radio-controlled model. A UBEC is needed when an electronic speed controller has no built-in BEC, or when the ESC's own BEC cannot power the number or size of servos being used.
This unit supports continuous simultaneous servo operation, which avoids overloading the speed controller's BEC during periods of high peak demand, such as extreme aerobatics. The output voltage is adjustable between 5V, 5.5V, 6V, 6.5V, 7V and 8V, and the input accepts 7-60V, covering 2-14S LiPo or 6-50 cell NiMH packs.
Battery polarity reversal protection and electromagnetic interference reduction are built in, along with an LED status indicator. The manufacturer describes it as easy to set up and install, and lists the connector as JR, Hitec and Futaba.
Specifications
- Output: adjustable 5V to 8V at 12A
- Input voltage: 7-60V
- Output current: 12A continuous, 18A burst
- Size: 60 x 34 x 15 mm
- Weight: 51 g
Secured by Stripe
ZTW Ubec 12A Manuals & Guides
Manuals & Guides
Specifications
A UBEC is needed if your Electronic Speed Controller (ESC) does not have a built in Battery Elimination Circuit (BEC). Theres also a requirement to fit a UBEC where the ESCs BEC is inadequate to power the number and / or size of servos being used. The ZTW UBEC range satisfies this requirement by supporting continuous simultaneous servo operations, thus eliminating the possibility of overloading your speed controllers BEC during periods of high peak demand (as might be experienced during extreme aerobatics).
Specification:
| Output: | Adjustable 5V / 5.5V / 6V / 6.5V / 7V / 8V at 12A |
| Input voltage: | 7 - 60V |
| Output current: | 12A continuous / 18A burst |
| Size (mm): | 60 x 34 x 15 |
| Weight (g): | 51 |
ZTW Ubec 12A Tech Specs:
ZTW Ubec 12A Key Features:
- A UBEC is needed if your Electronic Speed Controller (ESC) does not have a built in Battery Elimination Circuit (BEC). There's also a requirement to fit a UBEC where the ESC's BEC is inadequate to power the number and / or size of servos being used. The ZTW UBEC range satisfies this requirement by supporting continuous simultaneous servo operations, thus eliminating the possibility of overloading your speed controller's BEC during periods of high peak demand (as might be experienced during extreme aerobatics).
Specification:
Output: Adjustable 5V / 5.5V / 6V / 6.5V / 7V / 8V at 12A Input voltage: 7 - 60V Output current: 12A continuous / 18A burst Size (mm): 60 x 34 x 15 Weight (g): 51 - Switch mode
- Easy to set up and install.
- Battery polarity reversal protection.
- Electromagnetic interference reduction ensures optimum receiver performance.
- LED status indicator.
- Output voltage - 5.0V, 5.5V, 6.0V, 6.5V, 7.0V, 8.0V
- Input voltage - 7V - 60V (2-14S Lipo, 6-50 cell NiMH)
- Continues current output - 12A
- Peak current output - 18A
ZTW Ubec 12A Tech Specs:
- Weight: 51g / 1.80oz
- Shipping Weight: 0.06kg / 0.14lbs
- Product Height: 15mm / 0.59in
- Product Width: 34mm / 1.34in
- Product Length: 60mm / 2.36in
- Connector: JR | Hitec | Futaba
Key Info:
- Brand: ZTW
- Part No: ZTW300300010
- Barcode: 5051121222647
