Arrows Hobby SZD-54 Glider PNP 2000mm ARR017P
Brand: Arrows Hobby
Part No: ARR017P
Usually ships same day
Customers Also Buy
Popular with customers who buy products like the Arrows Hobby SZD-54 Glider PNP (2000mm)
Description
The Arrows Hobby SZD-54 Glider PNP (2000mm), part ARR017P, is a 2-metre-span aerobatic glider supplied in a plug-and-play configuration. Its EPO foam airframe features a 1000KV brushless motor, 30A ESC, six pre-installed 9g metal gear servos and a folding 12 x 6-inch propeller. Flaps, a three-point undercarriage and clip-on winglets support the model's powered flight and slope-soaring format.
The wing and tailplane use a bolt-free snap-fit retention system, while the winglets clip into place for assembly without screws. This arrangement allows the SZD-54 to be separated for storage and transport, then assembled at the flying site. A click-fit canopy latch provides access to the spacious battery compartment, which accepts a suggested 3S 1300–2200mAh LiPo battery with an XT60 connector.
As a PNP model, the motor, ESC and servos are factory installed. A six-channel transmitter and receiver combination, LiPo battery and compatible balance charger are required to complete the model. The factory-assembled and decorated fuselage, two-piece wing and tailplane are supplied alongside the winglet set, spar set, pushrods, Y-leads, spinner, folding propeller and instruction manual.
What's Included
- Factory-assembled and decorated fuselage and fin
- Factory-assembled and decorated two-piece wing
- Factory-assembled and decorated tailplane
- Winglet set and two-piece wing spar set
- Pre-installed 3136 1000KV brushless motor
- Pre-installed 30A ESC with XT60 connector
- Six pre-installed 9g metal gear servos
- Spinner and 12 x 6-inch folding propeller
- Pushrod set and Y-lead set
- Comprehensive instruction manual
Required to Complete
- Six-channel transmitter and receiver combination
- 3S 1300–2200mAh LiPo battery with XT60 connector
- 3S-compatible LiPo balance charger
Specifications
- Wingspan: 2,000mm
- Length: 1,096mm
- All-up weight with battery: 1,130g
- Motor: 1000KV brushless
- ESC: 30A
- Recommended battery: 3S 1300–2200mAh LiPo
Secured by Stripe
Arrows Hobby SZD-54 Glider PNP (2000mm) Manuals & Guides
Manuals & Guides
Specifications
Arrows first venture into glider guiding looks to have been undertaken with the same care and attention as its foray into EDF jets. The result is the striking SZD-54, 2M span, 3S, aerobatic slick ship, sporting flaps, a 1000KV brushless motor, six robust 9g servos, a quality 12 x 6 folder and a joyfully impressive performance.
Beautifully moulded in resilient EPO foam the SZD s cunning design incorporates a bolt-free snap-fit wing and stabiliser retention system sporting a convenience that s mirrored even in the clip-on winglets. All, of course, are details that allow the model to be easily stored and transported and, better still, quickly assembled at the patch or on the slope. Gorgeous lines, a sharp trim scheme and a versatile battery range only add to the pleasure of ownership but, rest assured, nothing can eclipse the kick you ll get when you fly it.
Specification:
| Wingspan (mm): | 2000 |
| Length (mm): | 1096 |
| Motor (KV): | 1000 |
| Rec'd battery: | 3S 1300 - 2200mAh |
| ESC (A): | 30 |
| All-up weight (g): | 1130 |
Arrows Hobby SZD-54 Glider PNP (2000mm) Tech Specs:
Arrows Hobby SZD-54 Glider PNP (2000mm) Key Features:
- Arrows first venture into glider guiding looks to have been undertaken with the same care and attention as its foray into EDF jets. The result is the striking SZD-54, 2M span, 3S, aerobatic slick ship, sporting flaps, a 1000KV brushless motor, six robust 9g servos, a quality 12 x 6 folder and a joyfully impressive performance.
Beautifully moulded in resilient EPO foam the SZD s cunning design incorporates a bolt-free snap-fit wing and stabiliser retention system sporting a convenience that s mirrored even in the clip-on winglets. All, of course, are details that allow the model to be easily stored and transported and, better still, quickly assembled at the patch or on the slope. Gorgeous lines, a sharp trim scheme and a versatile battery range only add to the pleasure of ownership but, rest assured, nothing can eclipse the kick you ll get when you fly it.
Specification:
Wingspan (mm): 2000 Length (mm): 1096 Motor (KV): 1000 Rec'd battery: 3S 1300 - 2200mAh ESC (A): 30 All-up weight (g): 1130 - Arrows first venture into glider guiding looks to have been undertaken with the same care and attention as its foray into EDF jets. The result is the striking SZD-54, 2M span, 3S, aerobatic slick ship, sporting flaps, a 1000KV brushless motor, six robust 9g servos, a quality 12 x 6 folder and a joyfully impressive performance.
Beautifully moulded in resilient EPO foam the SZD s cunning design incorporates a bolt-free snap-fit wing and stabiliser retention system sporting a convenience that s mirrored even in the clip-on winglets. All, of course, are details that allow the model to be easily stored and transported and, better still, quickly assembled at the patch or on the slope. Gorgeous lines, a sharp trim scheme and a versatile battery range only add to the pleasure of ownership but, rest assured, nothing can eclipse the kick you ll get when you fly it.
Specification:
Wingspan (mm): 2000 Length (mm): 1096 Motor (KV): 1000 Rec'd battery: 3S 1300 2200mAh ESC (A): 30 All-up weight (g): 1130 - Superb aerobatic performance.
- Bolt-free snap-fit wing and tailplane retention system.
- Takes a standard 3S 2200mAh LiPo.
- Sturdy three-point undercarriage arrangement.
- Aerodynamically efficient clip-on winglets.
- Flap-equipped.
- Made from lightweight, durable EPO foam.
- Clip together assembly (no screws needed).
- Spacious battery compartment.
- Supplied with pre-fitted motor, ESC and servos.
- Click-fit canopy latch.
What's in the Box:
- 1x Factory assembled and decorated fuselage and fin.
- 1x Factory assembled and decorated 2-piece wing.
- 1x Factory assembled and decorated tailplane.
- 1x Winglet set.
- 1x Pre-installed 3136 1000KV motor.
- 1x Pre-installed 30A ESC with XT60 connector.
- 6x Pre-installed high quality 9g metal gear servos.
- 1x Spinner and 12 x 6" folding propeller.
- 1x 2-piece wing spar set.
- 1x Pushrod set.
- 1x Y-lead set.
- 1x Comprehensive instruction manual.
Needed to Complete:
- 1x 6-channel transmitter and receiver combo.
- 1x 3S 1300 to 2200mAh LiPo with XT60 connector.
- 1x 3S compatible LiPo balance charger.
Arrows Hobby SZD-54 Glider PNP (2000mm) Tech Specs:
- Weight with Battery: 1130g / 39.86oz
- Shipping Weight: 3.40kg / 7.50lbs
- Product Length: 1,096mm / 43.1in
- Product Wingspan: 2,000mm / 78.7in
- Product Wing Area: 25dm2 / 389.05in2
- Connector: XT60
- Completion Level: PNP
- Experience Level: Beginner / Intermediate
- Assembly Time: 30min
- Recommended Usage Environment: Outdoors / large field
- Material: EPO
- Motor/Engine: 3136 1000KV brushless outrunner
- Servos: 6x 9g metal gear
- ESC: 30A with XT60 connector
Key Info:
- Brand: Arrows Hobby
- Part No: ARR017P
- Barcode: 5051121254372
- Power: Electric
- Flying Style: Gliders
- Assembly Level: PNP (Plug n Play) / RR
Delivery & Returns
Free Shipping
This item is over £100, so qualifies for free standard UK shipping!
Express Shipping
Upgrade to next day from £3
Worldwide Shipping
Available at checkout
Customer Reviews
No specific product reviews yet, why not write one?Questions & Answers
Hi yes here you go:
Transmitter and receiver FS-I6X-IA6BM2
Battery OL-3344
Charger HPI-118050
I hope this helps
Flight times are not quoted on gliders as they can vary depending on the wind and how much gliding is done rather than powered flight.
