FMS 1400mm T-28D Trojan V4 Red PNP (No Reflex)
Brand: FMS
Part No: FMS083PRD
Shadow Stock: Usually ships next day
Finance options available at checkout.
Description
The FMS 1400mm T-28D Trojan V4 Red PNP (part number FMS083PRD) delivers a major step forward over earlier versions, combining lighter EPO52 foam and durable, environmentally friendly water-based paint with a host of mechanical and power system upgrades. Supplied in PNP form without Reflex, it pairs the upgraded 4258-KV650 motor, 70A ESC and digital metal-gear servos with a refined airframe for precise control.
The latest FMS multi-connector simplifies wing removal to a single plug, while ball-link hardware tightens control response. Metal oleo struts with shock absorption front and rear improve ground handling and protect the airframe during firmer arrivals. A slide-out battery tray speeds pack changes, and screw-in servo pockets allow quick replacement when needed. Power and speed are quoted as around 30% higher than previous versions, enhancing overall flight appeal.
Features
- New upgraded 4258-KV650 motor and 70A ESC
- New technology lighter EPO foam
- New water-based painting for environmental protection
- Shock-absorbing metal oleo front and main landing gear struts
- Screw-in servo pockets; a bad servo can be replaced with 2 screws
- Digital metal gear servos throughout
- Ball links on all control surfaces
- Easy, single-wire quick connectors to remove the wings
- Slide-out battery tray for easy battery changes
Specifications
- Wingspan: 1400 mm (55.1 in)
- Overall length: 1185 mm (46.7 in)
- Flying weight: around 2450 g
- Motor: 4258-KV650 outrunner brushless
- ESC: 70 A brushless with 5 A SBEC and EC5 battery connector
- Servos: 9 g x 2, 17 g x 5
- Radio: 6-channel
- CG (centre of gravity): 80–85 mm from leading edge
- Propeller: 13 x 9 three-blade
- Recommended battery: Li-Po 14.8 V 2600 mAh
- Wing loading: 73.3 g/dm²
- Wing area: 33.4 dm²
Secured by Stripe
FMS 1400mm T-28D Trojan V4 Red - PNP Manuals & Guides
Manuals & Guides
Specifications
The FMS 1400mm T28 is going to get its fourth remarkable upgrade after it was launched three years ago. The 1400mm T28 V4 is coming!
No matter whether you had an FMS T28 or not before, the coming V4 is full of surprises. First of all, the foam ratio has been upgraded from EPO 40 to the lighter and larger EPO 52, which alleviates the airplane's weight, without weakening the airplane. Moreover, the original oil paint which has an unavoidable negative side effect of corrosion has been replaced by the latest environmental water-based paint.
Let’s take a look at more upgrades below. The latest FMS multi-connector is also used for V4, which makes the assembly easy and simple while leaving the wires orderly and user-friendly. The 1400mm T28 V4 adopts the new design of ball linkage to remove the clearance and hit an accurate flight. The updated 4258 motor drives the power and speed around 30% higher. Both front and rear landing gears are metal, with a shock absorption function for hard landings. In terms of construction and performance, the 1400mm T28 V4 is totally different to the old versions. It is certain that the latest version greatly enhances flight appeal. Don't miss out on this thrilling experience.
Features- New upgraded 4258-KV650 motor and 70A ESC
- New technology lighter EPO foam
- New water painting for environmental protection
- Shock absorbing metal oleo front and main landing gear struts
- Screw-in servo pockets. No more glued in servos! A bad servo can be replaced with 2 screws
- Digital metal gear servos throughout
- Ball links on all control surfaces
- Easy, single wire quick connectors to remove the wings
- Slide out battery tray for easy battery changes
Wingspan: 1400mm/55.1in
Overall Length: 1185mm/46.7in
Flying Weight: Around 2450g
Motor Size: 4258-KV650 Powerful Out Runner Brushless Motor
ESC: 70A Brushless ESC / 5A SBEC with EC5 Battery Connector
Servo: 9g Servo x 2, 17g Servo x 5
Radio: 6 Channel
CG (Center of Gravity): 80-85mm (From Leaging Edge)
Prop Size: 13*9 3 Blade Propeller
Recommended Battery: Li-Po 14.8V 2600mAh
Wing Load: 73.3g/dm2
Wing Area: 33.4dm2
For further information: on flying your RC plane in a safe and responsible manner please check out www.bmfa.org
Key Info:
- Brand: FMS
- Part No: FMS083PRD
- Barcode: 5056135763421
- Power: Electric
- Assembly Level: PNP (Plug n Play) / RR
- Flying Style: Sport
