Hobbywing Quicrun 3650 G2 17.5T Sensored Motor
Brand: Hobbywing
Part No: HW30404306
Out Of Stock
Request Stock NotificationThe Hobbywing Quicrun 3650 G2 17.5T Sensored Motor (HW30404306) delivers smooth, linear throttle response for 1/10 scale RC cars. A built-in Hall sensor with a non-adjustable end bell and a precision-balanced rotor provides predictable power on demand.
Thermal management is enhanced by a silicon O-ring between the end bell and stator, conducting heat into the motor case for improved cooling in demanding conditions. Maintenance is straightforward thanks to a removable end bell, allowing replacement of common wear parts such as the rotor, sensor module and bearings. Pre-soldered 3.5mm low-impedance bullet connectors offer a true plug-and-play connection to a suitable ESC.
For a matched drive feel, Hobbywing notes suggested compatibility with the QuicRun-10BL60-Sensored ESC, providing a smooth, linear power band when paired.
Key Features
- Linear & smooth control
- Great heat-dissipation
- Plug-and-play
- Re-buildable design
- Suggested compatibility with QuicRun-10BL60-Sensored ESC
- Built-in Hall sensor and balanced rotor for precise response
- Silicon O-ring aids heat transfer to the case
Specifications
- Scale: 1/10
- Type: Brushless
- Sensored: Yes
- Pole Count: 2
- KV Rating: 2170
- LiPo Cells: 2–3S
- No-load Current: 1.6A
- O.D.: 36mm
- Length: 52.8mm
- Shaft Diameter: 3.17mm
- Weight: 187g
- Timing: Fixed
Secured by Stripe
The built-in Hall sensor non-adjustable end bell combined with a high precision and balanced rotor guarantees the user a smooth and linear power on demand.
The silicon O-ring fitted between the end bell and stator helps to conduct inner heat to the unique motor case to maximize cooling for extreme cooling conditions. The end bell is easy to be removed for maintenance purposes and for the replacement of common wearing parts such as rotor and sensor module (Ex bearings).
Customized 3.5mm low impedance bullet connectors soldered to the motor wires guarantee "plug-and-play" and stable connections between the ESC and motor.
When pairing the QuicRun3650 G2 motor with the Hobbwing QuicRun-10BL60-Sensored ESC, the excellent match between ESC and motor will give you a very smooth and linear power band.
Hobbywing QuicRun 3650 SD G2 Features:
- Linear & Smooth Control
- Great Heat-dissipation
- Plug-and-Play
- Re-buildable Design
- Compatible (with QuicRun-10BL60-Sensored ESC)
Spec Check:
- Scale: 1/10th
- Brushed/Brushless: Brushless
- Sensored/Sensorless: Sensored
- Pole Count: 2
- KV Rating: 2170
- LiPo Cells: 2-3S
- No-load Current(A): 1.6
- O.D.(mm): 36 (1.147in)
- Length (mm): 52.8 (2.079in)
- Shaft Diameter (mm): 3.17 (0.125in)
- Weight: 187g
- Timing: Fixed
Key Info:
- Brand: Hobbywing
- Part No: HW30404306
- Barcode: 6938994412094
