Hobbywing XERun AXE 4274SD R3 1700Kv Black Sensored Motor

The Hobbywing XERun AXE 4274SD R3 1700Kv Black Sensored Motor (HW30401401) is a 4‑pole, sensored brushless motor for 1/8 and 1/6 applications, supporting 3–6S LiPo power. With a 42mm diameter can, 74mm length and a 5mm output shaft, it is well suited to rock crawling builds that benefit from precise, consistent control.

A sensored (SD) design can aid smooth startups and low‑speed resolution, while the 1700Kv wind offers a strong balance for crawling on 3–6S. The motor is listed with 12AWG leads at 250mm and no plug, giving flexibility for your preferred connector choice.

The 4274 size (42×74mm) and 405g weight make this a substantial unit for large‑scale crawler projects where steady throttle modulation is valued.

Key Specifications

• Scale: 1/8th, 1/6th
• Brushed/Brushless: BL (Brushless)
• Sensored/Sensorless: SD (Sensored)
• Pole Count: 4
• KV Rating: 1700Kv
• LiPo Cells: 3–6S LiPo
• No-load Current: 4A
• Outer Diameter (O.D.): 42mm
• Length: 74mm
• Shaft Diameter: 5mm
• Plug: No
• Wire: 12AWG × 250mm × 3
• Weight: 405g

ESC Pairing

Listed ESC: XERUN AXE PIUS R3.

Suggested Compatibility

• 1/8th and 1/6th rock crawlers
• Axial SCX6
• KM Ford Raptor F150
• Yikong YK4082
