Nosram N22 Modified Motor - 7.0T

The Nosram N22 Modified Motor – 7.0T (SCH-NR920011) is a high-performance sensored brushless power unit for 1:10 electric Modified racing. Part of Nosram’s Worlds Winning Pure Series, the N22 combines precision engineering with advanced cooling to deliver consistent power and efficiency under maximum loads.

An ultra‑lightweight, precision‑machined 7075‑T6 aluminium housing features maximised cut‑outs and extra openings on the flat surfaces, boosting cooling surface area and airflow for lower running temperatures. Finished in stealth black anodising with a distinctive N22 engraving, it’s a sleek match for modern race chassis.

Key Features

• Ultra‑lightweight 7075‑T6 aluminium can with enhanced cut‑outs for improved cooling and airflow
• Stealth black anodising with unique N22 engraving
• Precisely adjustable timing, optimised 14.5°–34.5° range for fine power delivery control
• 2017‑spec dual axis balanced sintered rotor with red balancing rings and longer mounting surface
• Updated internals for higher efficiency and vibration‑free operation
• Smaller dual precession 4×10×4 ABEC‑5 bearings for precise running and longevity
• 2017 PCB specification for reduced electrical resistance
• Waterproof PreciSensor for precise sensored operation with suggested compatibility across a wide range of speed controls; added advantages with Nosram ESCs

Technical Specifications

• Turn: 7.0T
• Type: Brushless, sensored
• Application: 1:10 electric Modified racing
• Timing Range: 14.5°–34.5°
• Rotor: 12.5 mm, dual axis balanced sintered
• Bearings: Dual precession 4×10×4 ABEC‑5
• Winding Style: Star (multistrand copper winding)
• Input Voltage: 1S–2S LiPo
• Length: 50.8 mm
• Diameter: 35.9 mm
• Weight: 159–164 g

Engineered for efficiency, cooling and precise control, the Nosram N22 7.0T offers a refined feel on track with robust construction and race‑focused features to help you extract maximum performance from your 1:10 Modified setup.
