Power HD R6 Gyro Servo 4.8Kg 0.09s
Brand: Power HD
Part No: HD-R6
£44.24
RRP £48.09
Shadow Stock: Usually ships within 4-5 days
The Power HD R6 Gyro Servo (HD-R6) is a compact, fast coreless servo engineered for precise control in RC applications. It offers a rapid 0.09s transit time at 6.0V, robust torque figures up to 7.5 kg-cm at 7.4V, and smooth operation thanks to dual ball bearings and copper/aluminium gearing.
Running on 6.0–8.4V DC and weighing just 28.5 g, the R6 balances speed, strength and efficiency in a small footprint. Its broad operating temperature range helps maintain consistent performance in varied conditions.
Key Specifications
- Torque: 6.5 kg-cm (6.0V) | 7.5 kg-cm (7.4V)
- Speed: 0.09 sec (6.0V) | 0.08 sec (7.4V)
- Operating Voltage: 6.0–8.4V DC
- Motor Type: Coreless
- Bearing Type: Dual ball bearings
- Gear Type: Copper & aluminium
- Working Frequency: 1520µs / 333Hz
- Operating Temperature: -20 to 60°C
- Weight: 28.5 g (1.01 oz)
- Size (L x W x H): 35.0 x 15.1 x 29.5 mm
Secure Payments
Secured by Stripe
Torque(6.0V): 6.5 kg-cm (90.27 oz/in)
Torque(7.4V): 7.5 kg-cm (104.16 oz/in)
Speed: 0.09 sec (6.0V) ¦ 0.08 sec (7.4V)
Operating Voltage: 6.0 ~ 8.4 DC Volts
Weight: 28.5 g (1.01 oz)
Bearing Type: Ball Bearing x 2
Motor Type: Coreless Motor
Gear Type: Copper & Aluminum
Operating Temperature: -20~60°C
Working frequency: 1520µs / 333hz
Size: 35.0 x 15.1 x 29.5 mm ( 1.38 x 0.59 x 1.136 in)
Key Info:
- Torque(6.0V): 6.5 kg-cm (90.27 oz/in)
- Torque(7.4V): 7.5 kg-cm (104.16 oz/in)
- Speed: 0.09 sec (6.0V) │ 0.08 sec (7.4V)
- Operating Voltage：6.0 ~ 8.4 DC Volts
- Weight: 28.5 g (1.01 oz)
- Bearing Type: Ball Bearing x 2
- Motor Type：Coreless Motor
- Gear Type：Copper & Aluminum
- Size：35.0 x 15.1 x 29.5 mm ( 1.38 x 0.59 x 1.136 in)
- Torque(6.0V): 6.5 kg-cm (90.27 oz/in)
- Torque(7.4V): 7.5 kg-cm (104.16 oz/in)
- Speed: 0.09 sec (6.0V) │ 0.08 sec (7.4V)
- Operating Voltage：6.0 ~ 8.4 DC Volts
- Weight: 28.5 g (1.01 oz)
- Bearing Type: Ball Bearing x 2
- Motor Type：Coreless Motor
- Gear Type：Copper & Aluminum
- Size：35.0 x 15.1 x 29.5 mm ( 1.38 x 0.59 x 1.136 in)
Key Info:
- Brand: Power HD
- Part No: HD-R6
- Barcode: 6939680301562
