RC4WD Yota Ultimate Scale Cast Axle (Front)

The Ultimate Scale Yota Cast Axles (Front)

The most Scale and complex Axle on the market just become a lot more affortable! Extremly scale to the smallest details, such as innovative round knuckles (just like the real thing), lower mounts (let shocks be mounted front or back) and compact offset pumpkin.

Specifications:

• Die Cast light Weight Metal Housing
• Hardened Steel Spool Gears
• 5mm Axle Output Shaft
• Full Ball Bearings
• Powdercated in black
• Width: 180mm / 7.09inch
• Engineered by Fracture in New Zealand
• Manufactured by RC4WD
• Designed for 1:10 Scale Truck!
• Hex to Hex Width: 179mm / 7.04"
• Pin to Pin Width: 168mm / 6.61"
• Pumpkin Height: 36.2mm / 1.42 "
• Leaf Mount Width: 79mm / 3.11"
• Gear Ratio: 2.67 : 1
• Output Shaft OD: 5mm / 0.19"
• 12mm Steel Wheel Hex

• Weight: 166g / 5.85oz

The actual product:

What's Included:

• 1x The Ultimate Scale Yota Cast Axle Housing (front)
• 2x Cast Knuckles
• 1x Steel Axle
• 1x Tracgear yota spool gear (Tracgear)
• 2x 12mm Steel Wheel Hex
• Complete hardwares and Bearings

Replacement Parts:

• Top and Bottom Axle case replacement (Z-A0078)
• Gear set (Z-S0027)
• Front Axle Shafts (Z-S0060)
• Third Member (Z-S0616)
• Steering Knuckles (Z-S0636)
• Replacement Hardware (Z-S0659)
• Bearing Kit for Yota Ultimate Scale Front Axle (Z-S0080)
• Yota 1/10 Axle Ring & Pinion Gears (Z-S0027)


Optional Parts & Upgrade:

• Ultimate 4 links mount (Z-S0133) (4mm spacer needed)
• RC4WD 12mm Mini Hex Wheel Widener Set (+15mm) (Z-S0407)
• Yota XVD axle (Z-S0342)
• 4 links mounts (Z-S0133)
• U bolt kit (Z-S0068)
• Straight replacement axle (Z-S0061)
• Yota Ultimate Scale Cast Straight Axle (Rear) (Z-A0061)

Optional Parts:

• Metal Shield Bearing 5x10x3mm (Z-S1334)
• RC4WD Rear Lock-Out set for Yota Portal Axles(Z-S1336)
• 5mm x 9mm x 0.3mm Axle Shims (Z-S1559)


What is the difference between this and billet Yota axles?

In terms of strength, cast version is about 85% in terms of strength of the billet version. All internals parts are the same as well.

• While some components may come assembled, it may be in your best interests to check the products to ensure all hardware is tight. In some cases you may want to apply threadlock to some of the hardware that is already installed.
• You can fit this Axle onto the New Tamiya Bruiser with (Z-S0518)
• Fits Trail Finder 2 Truck Kit w/Mojave Body Set (Z-K0042 "Disc_)
• RC4WD Trail Finder 2 Truck Kit w/Mojave II Body Set (Z-K0049)

• Same type Front Yota Axle (Silver)

Axle Shimming Video: Click Here

• Brand: RC4WD
• Part No: Z-A0058
• Barcode: 610373636517
