Team Associated B6 Arm Mount Inserts 1/0.5 (AS92011)
Brand: Associated
Part No: AS92011
In Stock: Usually ships same day
Finance options available at checkout.
Fits These Models (7)
Frequently Bought With
Other items customers often buy with the Team Associated B6 Series Arm Mount Inserts 1/0.5
Description
Team Associated AS92011 B6 Series Arm Mount Inserts 1/0.5 provide finer suspension tuning by adding a 0.5-step option between existing 1.0 increments. Molded in black plastic, these inserts let racers refine hinge pin height and toe-in/out positions for precise handling adjustments.
Features
- 0.5-step geometry tuning to fill gaps between 1.0 adjustments
- Holds the hinge pin 1 degree (0.7 mm) UP and 0.5 degree (0.35 mm) IN or OUT
- Rotated orientation allows 1 degree OUT and 0.5 degree UP or DOWN
- Type 1 and Type 2 cavities; install mirrored to maintain symmetry
- Moulded black plastic construction
- Eight inserts per pack
What’s Included
- Eight 1/0.5 arm mount inserts (black plastic)
Suggested Compatibility
- RC10B6
- RC10B6 Club Racer
- RC10B6.1
- RC10B6.1D
- RC10B6.1DL
- RC10B6.2
- RC10B6.2D
- RC10B6D
- RC10B64
- RC10B64 Club Racer
- RC10B64D
- RC10B74
- RC10SC6.1
- RC10T6.1
Secured by Stripe
Team Associated B6 Series Arm Mount Inserts 1/0.5 Manuals & Guides
Specifications
The AS92011 Arm Mount Inserts 1/0.5 are molded in black plastic and come with eight per package. Get these to try new settings not previously available with the current inserts. The 1/0.5 inserts help "fill in the blanks" and give a 0.5 step option where you previously only could adjust things in 1.0 steps, 1.0-up or 1.0-corner, filling out the finer settings on the outer perimeter of our current adjustment grid.
The new design holds the hinge pin 1 degree (or 0.7mm) offset UP and 0.5 degree (or 0.35mm) offset IN or OUT. When turned sideways, racers can do 1 degree OUT and 0.5 degree UP or DOWN.
There is a Type 1 and Type 2 cavity (hole locations must mirror each other) so you must watch when installing to keep them symmetrical. This visual chart is your master key showing part orientation.
Fits- RC10B6
- RC10B6 Club Racer
- RC10B6.1
- RC10B6.1D
- RC10B6.1DL
- RC10B6.2
- RC10B6.2D
- RC10B64
- RC10B64 Club Racer
- RC10B64D
- RC10B6D
- RC10B74
- RC10SC6.1
- RC10T6.1
Key Info:
- Brand: Associated
- Part No: AS92011
- Barcode: 784695920118
- Fitment: Standard Part
