Team Associated RC10B84 Carbon Front Arms AS92625

The Team Associated RC10B84/B84.1 73mm carbon front suspension arms, AS92625, are front suspension arms for the RC10B84 platform. These arms can be used on the B84 with the associated 73mm front-end components listed below, including the RC10T84 chassis and arm mounts. The B84 and B84.1 references identify the platform versions covered by the product name.

When used with the RC10T84 chassis, both the A and B mounts can fit the B84 chassis. However, the B mount does not key into the chassis correctly without the wide tongue provided by the RC10T84 chassis. The original side rail can also be used, although its front edge needs trimming. Alternatively, the RC10B84 V2 side rail or V2 Factory Team carbon side rail is listed for this arrangement.

Associated Parts

• AS92600 RC10T84 chassis
• AS92604 RC10T84 arm mount A
• AS92605 RC10T84 arm mount B
• AS92609 RC10T84 bumper set
• AS92614 RC10B84 side rail V2
• AS92615 RC10B84 Factory Team carbon side rail V2
• AS92622 RC10B84 front shock tower for 73mm arms
• AS92623 RC10B84 front shock tower cover for 73mm arms

Suggested Compatibility

Manufacturer information suggests compatibility with RC10B84D and RC10B84 models. The 73mm specification should be considered when matching these carbon front suspension arms with the related front shock tower, cover, chassis, mounts, bumper and side rail components.

• RC10B84D
• RC10B84
