Arrows Hobby BAE Hawk 50mm EDF Jet PNP ARR020P
Brand: Arrows Hobby
Part No: ARR020P
No longer available
This item has been discontinued and replaced by:
ReplacementArrows Hobby Hawk PNP with Vector Gyro (658mm)Part No: ARR020PV
View item
Customers Also Buy
Popular with customers who buy products like the Arrows Hobby BAE Hawk 50mm EDF - PNP
Description
The Arrows Hobby BAE Hawk 50mm EDF - PNP, part number ARR020P, is a semi-scale radio-controlled EDF jet with a 50mm 11-blade fan and pre-installed electronics. Its 2627 4500KV brushless motor is paired with a 30A ESC and is intended for a 3S LiPo power system. The model has a pre-painted EPO foam airframe, a one-piece wing and tailplane, and a magnet-retained canopy.
Designed for outdoor flying, the Hawk uses a retract-free layout and can be launched underarm. Its control system includes pre-installed digital servos for the aileron, elevator and throttle functions, with a standard four-channel transmitter and receiver combination suggested for operation. The glue-and-screw-together assembly is intended to take around 30 minutes, while the supplied 11-blade fan provides the EDF sound and airflow associated with this compact jet model.
The suggested battery range is a 3S 1300–2200mAh 30C LiPo with an XT60 connector. A 2200mAh battery is stated to provide more than eight minutes of flying time. The model represents the Red Arrows Hawk in a compact format, with a 662mm wingspan and 725mm length for transport and storage.
What's Included
- Factory-assembled and finished fuselage
- Factory-assembled one-piece wing and tailplane
- Pre-installed 2627 4500KV brushless motor and 50mm 11-blade fan
- Pre-installed 30A ESC with XT60 connector
- Three pre-installed 9g digital servos
- Screw set and instruction manual
Required to Complete
- Four-channel transmitter and receiver combination
- 3S 1300–2200mAh 30C LiPo with XT60 connector
- 3S-compatible LiPo balance charger
Specifications
- Wingspan: 662mm
- Length: 725mm
- All-up weight: 475g
- Motor: 2627 brushless, 4500KV
- Fan: 50mm 11-blade EDF
- ESC: 30A
Secured by Stripe
Arrows Hobby BAE Hawk 50mm EDF - PNP Manuals & Guides
Manuals & Guides
Specifications
Sleek, powerful and perfectly formed the Arrows Hobby Hawk will be something of an eye-opener to anyone who still thinks EDF jets have some catching up to do. Experience the Hawk in action and you ll quickly realise that nothing could be further from the truth. Packing a sweet-sounding 50mm 11-blade fan that s spun up by a precision 2627 4500KV brushless motor, this 3S-fuelled semi-scale Red Arrows jet can t fail to delight with its flowing aerobatics, cloud punching performance and exceptional speed. But that s not the half of it, the Hawk is also a beautifully practical model that exhibits exceptional low speed handling, is small enough to transport in one piece, is retract (hassle) free and, moreover, gets away easily from an underarm launch. Given that it s enticingly budget-friendly and such a good performer, we just know that the Hawk will become a frequent flyer in your air fleet and, of course, that equates to superb value for money.
Specification:
| Wingspan (mm): | 662 |
| Length (mm): | 725 |
| Motor (KV): | 4500 |
| Rec'd battery: | 3S 2200mAh |
| ESC (A): | 30 |
| All-up weight (g): | 475 |
Arrows Hobby BAE Hawk 50mm EDF - PNP Key Features:
- High quality pre-painted EPO foam airframe.
- Glue- and screw-together assembly.
- Proven pre-installed hardware.
- Superior ball joint control linkages.
- Outstanding power-to-weight ratio.
- Secure magnet-retained canopy.
- Retract-free, fly anywhere simplicity.
- Suits 3S 11.1V 1300 2200mAh 30C LiPo.
- Three pre-installed high-quality digital servos.
- Takes standard 4-channel radio (aileron, elevator, throttle).
- Smooth-sounding 11-blade fan.
- 30-minute assembly time.
- 8+ minutes on a 2200mAh LiPo.
What's in the Box:
- 1x Factory assembled and finished fuselage.
- 1x Factory assembled and finished 1-piece wing.
- 1x Factory assembled and finished 1-piece tailplane.
- 1x Pre-installed 2627 4500KV brushless motor.
- 1x Pre-installed 50mm 11-blade fan.
- 1x Pre-installed 30A ESC with XT60 connector.
- 3x Pre-installed high quality 9g digital servos.
- 1x Screw set.
- 1x Comprehensive instruction manual.
Needed to Complete:
- 1x 4-channel transmitter and receiver combo.
- 1x 3S 1300 – 2200mAh 30C LiPo with XT60 connector.
- 1x 3S compatible LiPo balance charger.
Arrows Hobby BAE Hawk 50mm EDF - PNP Tech Specs:
- Shipping Weight: 1.95kg / 4.30lbs
- Product Length: 725mm / 28.5in
- Product Wingspan: 662mm / 26.0in
- Product Wing Area: 9dm2 / 133.30in2
- Completion Level: PNP
- Experience Level: Intermediate / expert
- Assembly Time: 30min
- Recommended Usage Environment: Outdoors
- Material: EPO
- Motor/Engine: 1x Brushless 2627 4500KV
- Servos: 3x 9g digital
- ESC: 1x 30A ESC with XT60 connector.
Key Info:
- Brand: Arrows Hobby
- Part No: ARR020P
- Barcode: 5051121256499
- Flying Style: EDF Jets
- Power: Electric
- Assembly Level: PNP (Plug n Play) / RR
