E Flite 80 AMP Pro Switch-Mode BEC Brushless ESC EC5 Connector (V2) ** CLEARANCE **
Brand: E Flite
Part No: EFLA1080B
In Stock: Usually ships same day
The E-flite 80 Amp Pro Switch-Mode BEC Brushless ESC (V2), part EFLA1080B, is a high-quality sensorless speed controller designed for demanding, high-current applications. Its integrated switch-mode BEC powers the receiver and servos without a separate receiver pack, helping reduce weight and complexity. Supporting 3–6 cell Li-Po or 9–18 cell Ni-MH/Ni-Cd input, it delivers up to 80A continuous current with proper airflow and 100A burst capability.
A finned aluminium heat sink case, safe power-arming and extensive programming options make this a versatile choice for fixed-wing and helicopter setups. Pre-wired connectors include an EC5 on the battery input and 4.0mm female gold bullets on the motor leads for straightforward installation.
Key Features
- Up to 80A continuous current (with proper airflow) and 100A burst for 15 seconds
- Switch-mode BEC rated to 5A continuous (6A max burst)
- Drives up to 7 analog or 6 digital standard-size servos via the BEC on any recommended input voltage
- Input voltage: 3–6S Li-Po, 9–18 cell Ni-MH/Ni-Cd
- Programmable motor braking
- Safe power-arm mode helps prevent accidental starts
- Programmable low-voltage cutoff: presets for 3S (9.2V), 4S (12V), 5S (15V), 6S (18V) or 74% of starting voltage
- Programmable throttle input range: 1.1–1.9ms or 1.2–1.8ms
- Programmable soft start-up: 0.25s or 1s
- Auto motor shutdown on signal loss or interference
- Five user-selectable timing ranges for broad motor compatibility
- Two operating modes: Airplane or Heli
- Pre-wired connectors: EC5 battery input and 4.0mm female gold bullets on motor outputs
- Overload protection
- Note: Not recommended for use with the E-flite Power 60 Brushless Outrunner (EFLM4060B)
Specifications
- Maximum burst current: 100A
- BEC continuous current: 5A
- Brakes: Yes (including time delay brake)
- Programmable settings and auto cutoff: Yes
- Connectors: EC5 (battery), 4.0mm female bullets (motor)
Suggested Compatibility
- Sensorless brushless power systems in RC aeroplanes and helicopters using 3–6S Li-Po or 9–18 cell Ni-MH/Ni-Cd packs and requiring up to 80A continuous current
This product is not intended for use by children under 14 years of age without direct adult supervision.
Secured by Stripe
When performance matters in your high-current applications, look no further than the E-flite® 80-amp Pro switch-mode ESC. This is a high-quality, efficient sensorless brushless electronic speed control with an integrated switch-mode BEC. It can operate without the need for a separate receiver battery to power your servos and receivers, saving you weight and complication. It is capable of up to 80 amps continuous current when using 3- to 6-series Li-Po battery packs. You can drive up to 7 analog or 6 digital standard-size servos with the BEC on any recommended input voltage. Featuring an exposed, finned heat sink aluminum case with lightweight plastic end-caps, safe power-arming along with advanced programmable features such as low voltage cutoff, braking, timing, throttle input range and more, the E-flite 80-amp Pro switch-mode ESC is truly a ‘pro series’ electronic speed control.
This product is not intended for use by children under 14 years of age without direct adult supervision.
E Flite 80 Amp Pro Switch-Mode BEC Brushless ESC EC5 Connector (V2) ** CLEARANCE ** Features:- Up to 80 amps continuous current with proper air flow and 100 amps burst current (15 seconds)
- 5V switch-mode BEC capable of 5 amps continuous current with 6 amps max burst on any recommended input voltage
- Drive up to 7 analog or 6 digital standard-size servos with the BEC on any recommended input voltage
- 3- to 6-cell Li-Po, 9- to 18-cell Ni-MH/Ni-Cd input voltage
- Programmable motor braking
- Safe power-arm mode prevents accidental starts
- Programmable low voltage cutoff with settings for 3-cell Li-Po (9.2V), 4-cell Li-Po (12V), 5-cell Li-Po (15V), 6-cell Li-Po (18V) or 74% of battery starting voltage
- Programmable throttle input range (1.1ms–1.9ms or 1.2ms–1.8ms)
- Programmable soft start-up rate - .25 second or 1 second
- Auto motor shut down if signal is lost or there is interference
- Programmable timing—5 user-selectable ranges–use with a large variety of brushless motors
- Two operating modes–Airplane or Heli
- Pre-wired connectors—E-flite EC5 on battery input and 4.0mm female gold bullets on motor output leads
- NOTE: Not recommended to use with E-flite Power 60 Brushless Outrunner (EFLM4060B)
E Flite 80 Amp Pro Switch-Mode BEC Brushless ESC EC5 Connector (V2) ** CLEARANCE ** Specfications:
- Amperage: 60 & Up
- Brakes: Yes
- Programmable: Yes
- Auto Cutoff: Yes
- BEC Continous Current: 5A
- Output Connector: 4mm Bullet
- Overload Protection: Yes
- Maximum Burst Current: 100A
- BEC Voltage: 5.5V Switch-mode
- Part Type: Electronics
- Time Delay Brake: Yes
- Connector Type: EC5
- Forward: Yes
Key Info:
- Brand: E Flite
- Part No: EFLA1080B
- Barcode: 605482053102
- Fitment: Option Part
Additional Categories:
Free Shipping
This item is over £100, so qualifies for free standard UK shipping!
Express Shipping
Upgrade to next day from £3
Worldwide Shipping
Available at checkout
Reviews
No specific product reviews yet, why not write one?WRITE A REVIEW
Questions & Answers
Dimensions are:
45mm width
20mm height
Length wise you would need around 90mm (this takes into account the actual ESC size and the room required for the wires coming out of the side of it).
Yes, this will work without any issues at all
Yes as per the picture it has a slide on and off switch.
