LRP V10 Spec6 12x2 Brushed Motor (540)
Brand: LRP
Part No: SCH-LRP57126
In Stock: Usually ships same day
Finance options available at checkout.
Frequently Bought With
Other items customers often buy with the LRP V10 Spec6 - 12 x 2 Brushed Motor
Description
The LRP V10 Spec6 – 12 x 2 Brushed Motor brings the brand’s 2021 brushed technology into the iconic LRP housing. Designed for brushed classes and vintage racers, it delivers super-smooth throttle response across the entire RPM range with strong, consistent power.
This 540-size, timeable 2-pole/3-slot motor uses high-power precision windings and robust magnets, and is fully rebuildable to support a longer service life and durable performance.
Features
- Popular precision windings inside the iconic LRP housing
- Super-smooth throttle response across the RPM range
- High-power magnets for convincing holding power
- Fully rebuildable design for extended lifetime and performance
Technical Data
- Type: 540 brushed, timeable
- Configuration: 2 pole, 3 slot
- RPM (at 7.2V): 36,000
- Voltage input: 3.7 – 7.6V
- Shaft diameter: 3.17mm
- Motor diameter: 35.9mm
- Weight: 156g (±5%)
Secured by Stripe
LRP V10 Spec6 - 12 x 2 Brushed Motor Manuals & Guides
How-To Guides & Articles
Specifications
POPULAR WINDINGS
HIGH-POWER PRECISION WINDINGS INSIDE THE ICONIC LRP HOUSING. PERFECT FOR ALL BRUSHED CLASSES AND VINTAGE RACERS.
SMOOTH RESPONSE
SUPER SMOOTH THROTTLE RESPONSE OVER THE ENTIRE RPM RANGE.
HIGH-POWER MAGNETS
STRONG MAGNETS PROVIDE CONVINCING HOLDING POWER, NO MATTER WHICH HILL YOU ARE STANDING ON.
FULLY REBUILDABLE
FULL REBUILDABLE MOTORS FOR LONGER LIFETIME AND DURABLE PERFORMANCE
TECHNICAL DATA
Type - 540 Brushed, timeable 2 Pole - 3 Slot
RPM - (at 7.2V)36.000
Voltage input - 3.7 - 7.6V
Shaft diameter - 3.17mm
Motor diameter - 35.9mm
Weight - 156g (+/-5%)
Key Info:
- Brand: LRP
- Part No: SCH-LRP57126
- Barcode: 5051294172954
Delivery & Returns
Standard Shipping
£3.95 to most of the UK
Express Shipping
£6.95 to most of the UK
Worldwide Shipping
Available at checkout
Customer Reviews
No specific product reviews yet, why not write one?Questions & Answers
This motor will not work on the Hobbywing 1060 and I suspect would be to much for the lunchbox .
