Popular with customers who buy products like the Multiplex ROXXY BL Outrunner C35-48-1150kV
Description
The Multiplex ROXXY BL Outrunner C35-48-1150kV (part number MPX315082) is a 14-pole brushless outrunner motor with neodymium magnets, rated at 1150kV and designed for a 7 - 12V supply.
As an outrunner, the motor needs no reduction gearbox. Its construction gives efficient, high-torque power and often allows large propellers to be driven directly, which makes it well suited to direct-drive applications.
Multiplex fit a maximum copper fill ratio and neodymium magnets to keep the motor efficient, while large precision ballraces help it run smoothly. The motor can be mounted from either end, giving some flexibility when planning an installation. It has a silver and black finish with steel construction and bullet connectors.
Specifications
- Motor type: 14-pole brushless outrunner
- Speed constant: 1150kV
- Voltage: 7 - 12V
- Weight: 250 g (8.82 oz)
- Connector: Bullet
- Colour: Silver and black
- Material: Steel
- Age recommendation: 14+
Secured by Stripe
Multiplex ROXXY BL Outrunner C35-48-1150kV Manuals & Guides
Specifications
14-pole brushless outrunner motors
Brushless motors with neodymium magnets represent the very latest form of electric power plant. Outrunners in particular require no reduction gearbox, and constitute efficient, high-torque motors covering a broad range of power levels.
The special construction of outrunner motors often enables them to drive large propellers without the need for a gearbox, so they are ideal for direct-drive applications.
- Maximum copper fill ratio and superior neodymium magnets for high efficiency
- Large, precision ballraces ensure smooth running
- Can be mounted by either end
Multiplex ROXXY BL Outrunner C35-48-1150kV Key Features:
- 1150kV
- 7 - 12V
Multiplex ROXXY BL Outrunner C35-48-1150kV Tech Specs:
- Weight: 250g / 8.82oz
- Shipping Weight: 0.25kg / 0.56lbs
- Connector: Bullet
- Age Recommendation: 14+
- Colour: Silver + Black
- Material: Steel
Key Info:
- Brand: Multiplex
- Part No: MPX315082
- Barcode: 4041033170823
