Overlander XP2 60A SBEC Brushless ESC – RTF
Brand: Overlander
Part No: OL-2721
Out Of Stock
Request Stock NotificationFinance options available at checkout.
Frequently Bought With
Other items customers often buy with the Overlander XP2 60A SBEC Brushless ESC - RTF Speed Controller
Description
The Overlander XP2 60A SBEC Brushless ESC – RTF Speed Controller (OL-2721) arrives ready to fly, factory-fitted with a Deans battery connector and 4mm gold motor connectors. It provides a solid 5A/5V SBEC and wide input support from 2–6S Li-Po or 5–18 NiMH, with straightforward setup via a program card or the ESC key.
Key Features
- Full protection suite: low voltage, over-heat, throttle signal loss, startup protection and self-check
- Suggested compatibility with most sensorless brushless motors
- Excellent startup performance, smooth throttle linearity and quick throttle response
- Supports up to 210,000 RPM (2-pole), 70,000 RPM (6-pole) and 35,000 RPM (12-pole)
- Easy configuration with program card
- Automatic detection of throttle neutral point
- Three timing modes to match different motors
- Three start-force settings
- Governor mode for heli applications
- Reverse motor direction
- Pre-fitted Deans battery plug and 4mm gold bullets
Specifications
- Continuous current: 60A (80A burst for 10 seconds)
- Input voltage: 2–6 cell Li-Po or 5–18 cell NiMH
- SBEC output: 5V / 5A
- Low resistance PCB
- Dimensions: 77 x 35 x 14 mm
- Weight: 53.4 g
- Battery leads: 12AWG (red/black)
- Motor leads: 14AWG (blue)
- Motor connectors: 4mm gold
BEC Usage Guidance
Manufacturer guidance typically limits servo count to roughly one servo per 1A of BEC output. Overlander advises considering a separate receiver pack or an uprated UBEC when using four servos or more.
Secured by Stripe
Overlander XP2 60A SBEC Brushless ESC - RTF Speed Controller Manuals & Guides
How-To Guides & Articles
Specifications
Overlander XP2 60A SBEC Brushless ESC - RTF Speed Controller
READY TO FLY! - Now fitted with Deans connector for the battery and 4mm gold connectors for the motor!
This series of speed controllers have high technology and perfect function. Aiming at none-hall direct current brushless motors, they can set several parameters through program card or key on ESC and are convenient to use.
XP2 SBEC 60A Brushless speed controller features:
• Full protection feature including low voltage, over-heat, throttle signal lost, startup protection and self-check.
• Compatible with most sensor less brushless motors.
• Excellent startup performance, great throttle linear and quick throttle response.
• Support highest motor speed 210,000RPM (2 poles), 70,000RPM (6 poles) and 35,000(12 poles).
• Easy configured with program card.
• System can automatically detect throttle neutral point.
• 3 timing modes can match different motors.
• 3 modes of start force adjustment.
• Governor mode for heli
• Reverse motor direction
SPECIFICATION
• Low resistance PCB
• Input Voltage: Support 2-6 cell Li-Po, 5-18 Nimh
• Continue current: 60A, (Burst max 80A 10 secs)
• BEC output: 5A/5V
• Dimensions: 77 x 35 x 14 mm
• Weight: 53.4g
• Blue Motor Wire 14AWG
• Red and Black Battery Wire 12AWG
• 4mm gold connectors
Manufacturers recommend Servo numbers to be limited to 1 servo per 1A of BEC. At Overlander we say you should consider a separate RX pack or uprated UBEC when using 4 servos or more
Key Info:
- Brand: Overlander
- Part No: OL-2721
- Barcode: 5060386115649
