RC4WD Outcry III Waterproof ESC (Z-E0113)
Brand: RC4WD
Part No: Z-E0113
Out Of Stock
Request Stock NotificationFinance options available at checkout.
Description
The RC4WD Outcry III Waterproof ESC (Z-E0113) delivers dependable control for scale trail builds. It combines a robust 6V/3A BEC, high current handling and waterproof construction, making it well suited to all-weather use on the trail.
Supporting 2–3S LiPo or 5–9 cell NiMH packs, this unit includes LiPo protection when using 2S (half speed at 6.5V and shut-off at 6.0V). Compact dimensions and light weight simplify installation in tight scaler chassis.
Key Features
- Waterproof construction for all-weather conditions
- Advanced Turbo BEC with 6V/3A output
- High output current: 320A forward / 180A reverse
- Integrated 2S LiPo cutoff behaviour for added protection
- Compact and lightweight for easy installation
- Running mode regulator included
Specifications
- Input voltage: 2–3S LiPo / 5–9 cells NiMH
- BEC output: 6V / 3A
- Output current: 320A forward, 180A reverse
- Suggested compatibility: 540 brushed motors
- Size: 36.5 x 32 x 18 mm
- Weight: 39 g
What’s Included
- 1x Outcry III Waterproof ESC
- 1x Running Mode Regulator
- 1x 3M Double-Faced Adhesive Tape
- 1x Appearance Sticker
Optional Parts
- 540 Crawler Brushed Motor 80T (Z-E0001)
- 540 Crawler Brushed Motor 65T (Z-E0002)
- 540 Crawler Brushed Motor 55T (Z-E0003)
- 540 Crawler Brushed Motor 45T (Z-E0004)
- 540 Crawler Brushed Motor 35T (Z-E0005)
- RC4WD Brushed 45T Boost Rebuildable Crawler 540 Motor (Z-E0041)
- Brushed 35T Boost Rebuildable Crawler 540 Motor (Z-E0045)
- 540 Crawler Brushed Motor 20T (Z-E0065)
- 540 Crawler Brushed Motor 27T (Z-E0067)
- "T" Style Male to Tamiya Female Connector Adapter (Z-E0087)
Instruction Manual
- Download available from the manufacturer
Notes
- Before setup, remove the motor pinion or raise the vehicle so wheels cannot touch the ground.
- Do not touch the ESC while in use; the heatsink can become extremely hot.
- Waterproof to a depth of up to 10 cm for 2 hours.
Secured by Stripe
RC4WD Outcry III Waterproof ESC RC4WD Manuals & Guides
Specifications
Outcry III Waterproof ESC
This new Outcry II Waterproof ESC features great characteristics for scale trail driving, making it the perfect choice for any scale build!
Specifications:
- Input Voltage: 2-3S Lipo/5-9 Cells NiMH
- Advanced Turbo BEC
- BEC Output Voltage-Current: 6V-3A
- Output Current: 320A Forward, 180A Reverse
- Applicable to All Weather Conditions
- LiPo Cutoff (Using 2S, half speed at 6.5V and shut off at 6V)
- Proper Motors: 540 Brushed Motors
- Size: 1.43 x 1.26 x 0.70in / 36.5 x 32 x 18mm
- Weight: 1.37oz / 39g
What's Included:
- 1x Outcry III Waterproof ESC
- 1x Running Mode Regulator
- 1x 3M Double Faced Adhesive Tape
- 1x Appearance Sticker
Optional Parts:
- 540 Crawler Brushed Motor 80T (Z-E0001)
- 540 Crawler Brushed Motor 65T (Z-E0002)
- 540 Crawler Brushed Motor 55T (Z-E0003)
- 540 Crawler Brushed Motor 45T (Z-E0004)
- 540 Crawler Brushed Motor 35T (Z-E0005)
- RC4WD Brushed 45T Boost Rebuildable Crawler 540 Motor (Z-E0041)
- Brushed 35T Boost Rebuildable Crawler 540 Motor (Z-E0045)
- 540 Crawler Brushed Motor 20T (Z-E0065)
- 540 Crawler Brushed Motor 27T (Z-E0067)
- "T" Style Male to Tamiya Female Connector Adapter (Z-E0087)
Instruction Manual:
- Click here to download
Notes:
- Prior to proceeding, be sure to either remove the pinion from the motor or elevate the truck so the wheels are not able to touch the ground.
- Do not touch this product while in use to avoid injury. Product emits heat and thus, the heatsink may become extremely hot.
- This product is waterproof. Product will be functional in up to 10cm of water for 2 hours.
Key Info:
- Brand: RC4WD
- Part No: Z-E0113
- Barcode: 639302597415
- Fitment: Standard Part
