Multiplex ROXXY BL Outrunner C22-16-18 2570kV
Brand: Multiplex
Part No: MPX314945
Out Of Stock
Request Stock NotificationFinance options available at checkout.
Description
The Multiplex ROXXY BL Outrunner (C22-16-18) is a compact 14‑pole brushless outrunner motor engineered for efficient, high‑torque direct‑drive applications. Superior neodymium magnets and a high copper fill contribute to excellent efficiency, while large precision ballraces ensure smooth, reliable running. Flexible installation is aided by the option to mount the motor by either end.
Key Features
- 2570kV
- 100W
- 14‑pole brushless outrunner design
- Maximum copper fill ratio with superior neodymium magnets for high efficiency
- Large, precision ballraces for smooth running
- Can be mounted by either end
- Ideal for direct‑drive applications
Tech Specs
- Part Number: MPX314945
- Model: ROXXY BL Outrunner (C22-16-18)
- Motor Diameter: 22mm
- Shaft Diameter: 2mm
- Length: 23mm
- Weight: 19g
- Connector: Bullet
- Colour: Silver
- Material: Steel
- Age Recommendation: 14+
Secured by Stripe
ROXXY BL Outrunner (C22-16-18) Manuals & Guides
Specifications
14-pole brushless outrunner motors
Brushless motors with neodymium magnets represent the very latest form of electric power plant. Outrunners in particular require no reduction gearbox, and constitute efficient, high-torque motors covering a broad range of power levels.
The special construction of outrunner motors often enables them to drive large propellers without the need for a gearbox, so they are ideal for direct-drive applications.
- Maximum copper fill ratio and superior neodymium magnets for high efficiency
- Large, precision ballraces ensure smooth running
- Can be mounted by either end
ROXXY BL Outrunner (C22-16-18) Key Features:
- 2570kV
- 100W
- 22mm motor diameter.
- 2mm shaft diameter.
Manuals & Parts Explosions:
ROXXY BL Outrunner (C22-16-18) Tech Specs:
- Weight: 19g / 0.67oz
- Shipping Weight: 0.08kg / 0.18lbs
- Product Length: 23mm / 0.91in
- Product Diameter: 22mm / 0.87in
- Connector: Bullet
- Age Recommendation: 14+
- Colour: Silver
- Material: Steel
Key Info:
- Brand: Multiplex
- Part No: MPX314945
- Barcode: 4041033109458
