Spektrum Firma 35T Rebuildable Crawler Motor (SPMXSM5353)
Brand: Spektrum
Part No: SPMXSM5353
Expected Mon 30 Nov
Request Stock NotificationFinance options available at checkout.
Fits These Models (5)
Customers Also Buy
Popular with customers who buy products like the Spektrum Firma 35T Rebuildable 3-Pole Brushed Crawler Motor
Description
The Spektrum Firma 35T Rebuildable 3-Pole Brushed Crawler Motor (SPMXSM5353) is a 540-size option designed to deliver smooth low-speed control, strong torque and excellent efficiency for trail driving. Its fully rebuildable design and adjustable timing make it easy to maintain and tune for consistent performance.
Key Benefits
- 3-pole design: Proven balance of torque, efficiency and throttle feel.
- Fully rebuildable: Replace brushes, springs and bearings to extend service life.
- Adjustable timing: 0–20 degrees for expert-level tuning and performance gains.
Features
- 540 can size for 1/10-scale applications
- Adjustable timing for clockwise or counterclockwise rotation
- Pre-shaped curved face brushes – no break-in period required
- Wires with 3.5mm bullet connectors installed – no soldering required
- Dual rubber sealed bearings
- Fully rebuildable with accessible commutator
Specifications
- Turns: 35T
- Motor type: Brushed, 3-pole
- Can size: 540
- Length: 53 mm (2.1 in)
- Outer diameter: 36 mm (1.4 in)
- Shaft diameter: 3 mm (0.125 in)
- Weight: 169 g (6.0 oz)
- Forward/Reverse: Yes
- Adjustable timing: 0–20 degrees
- Bearings: Dual rubber sealed
- Connector: 3.5 mm bullet
- Water-resistant: No
- Application: Crawling, surface; 1/10 scaler/crawler
Suggested Compatibility
- 1/10 scale crawlers and scalers using 540-size brushed motors
- Brushed ESCs with 3.5 mm bullet motor outputs (as applicable)
What’s Included
- (1) Spektrum Firma 3-Pole Rebuildable Brushed 35 Turn Motor
- (1) Product manual
Required To Complete
- (1) Brushed ESC, 40 A or higher
Secured by Stripe
Spektrum Firma 35T Rebuildable 3-Pole Brushed Crawler Motor Manuals & Guides
Manuals & Guides
Specifications
The Spektrum Firma 3-Pole Rebuildable Brushed Motors offer an impressive low-cost upgrade for brushed esc equipped 1/10th scale Crawlers and Scalers. Featuring fully rebuildable design, impressive torque and speed, and excellent efficiency.
Key Benefits- 3-Pole Design: Industry standard design for max torque and efficiency
- Fully Rebuildable: Easy to replace parts for simple maintenance and increased motor lifespan
- Adjustable Timing: 0 to 20 degree timing adjustments for expert level tuning and increased performance
- Available in 35, 55, and 80 Turn configurations
- 540 can size – perfect upgrade for most 1/10th scale vehicles
- Adjustable timing for clockwise and counterclockwise motor rotation
- Pre-shaped curved face brushes – No break-in period required!
- Wires and 3.5mm bullets installed – No soldering required!
- Dual rubber sealed bearings
- Fully rebuildable with an easily accessible commutator and replaceable brushes, springs, and bearings.
Spektrum Firma 35T Rebuildable 3-Pole Brushed Crawler Motor Specifications:
- Adjustable Timing: Yes
- Application: 1/10 Scaler/Crawler
- Bushing Or Bearing: Bearing
- Connector Type: 3.5mm Bullet
- Forward: Yes
- Motor Output Lead: 3.5
- Motor Size: 540-Size
- Motor Type: Brushed
- Number of Poles: 3
- Outer Diameter: 1.4" (36 mm)
- Product Application: Crawling, Surface
- Product Length: 2.1" (53 mm)
- Product Weight: 169g (6.0 oz)
- Reverse: Yes
- Shaft Diameter: 0.125" (3 mm)
- Turns: 35T
- Water-Resistant: No
What's in the Box:
- (1) Spektrum Firma 3–Pole Rebuildable Brushed 35 Turn Motor
- (1) Product Manual
Spektrum Firma 35T Rebuildable 3-Pole Brushed Crawler Motor Requires to Complete:
- (1) Brushed ESC 40 Amp or Higher
Key Info:
- Brand: Spektrum
- Part No: SPMXSM5353
- Barcode: 0605482124918
- Fitment: Option Part
- Fitment: Standard Part
Additional Categories:
