Tamiya RC Squash Van (GF-02) 1/10 Kit - HC-58725
Brand: Tamiya
Part No: HC-58725
Out Of Stock
Request Stock NotificationFinance options available at checkout.
Save with a Combo Package
Our recommended kit, bundled at a combined priceAdd a radio system, steering servo, batteries and charger to your new model. Note, you may also wish to choose some bodyshell paint from our range.
1× eTronix Pulse EX2 Sport - 2 Channel 2.4Ghz Radio Set
1× EP Super Duty 3000mAh NiMh Stick Pack - 7.2v - Tamiya Connector
1× Power HD 1812MG Waterproof Metal Geared Servo - 18kg - 0.12s
1× Team Orion IQ801 1 AMP NiMh Charger With Deans to Tamiya Adapter
Add a better specification radio system, steering servo, higher capacity battery and fast charger to your new Tamiya model. Note, you may also wish to choose some bodyshell paint from our range.
2× HPI Plazma 1.5V Alkaline AA Battery (4Pcs)- 1× eTronix Pulse EX2 Sport - 2 Channel 2.4Ghz Radio Set
1× Voltz 5300mAh NiMh Stick Pack - 7.2v - Tamiya Connector
1× eTronix Power Pal Peak Detect NiMh Fast Charger - Mains/12v Input
1× Savox SW0231MG+ Waterproof Metal Gear Digital Servo - 15kg - 0.17s
Frequently Bought With
Other items customers often buy with the Tamiya RC Squash Van (GF-02)
Description
The Tamiya RC Squash Van (GF-02) is a 1/10-scale R/C assembly kit inspired by classic 1950s American panel vans. Riding on Tamiya’s gear-driven 4WD GF-02 chassis, it blends a realistic long wheelbase with big-lug tyres for confident driving on grass and rough ground. Part number HC-58725 includes an ESC and Type 540 motor.
Key Features
- 1/10 scale kit. Length: 454mm, width: 280mm, height: 238mm. Wheelbase: 267mm.
- Large 123mm lug-pattern tyres for strong traction and sure-footed handling.
- Sticker set with squash illustrations, product logo, and triple pinstripes in gold, black and blue.
- Electronic speed controller (ESC) and Type 540 motor included.
GF-02 Chassis Overview
- Gear-driven 4WD with motor mounted low and centrally in a lightweight, durable monocoque frame.
- Power delivered to front and rear via gears; integrated sealed gearboxes help keep stones out.
- Long wheelbase and wide tread for stability off-road. Tread: Front 223mm / Rear 221mm.
- Front and rear gear differentials for smooth cornering.
- 4-wheel double wishbone suspension with four friction dampers.
- Slim frame with ladder/pipe motifs and an included motor guard.
- Steering servo positioned on the left with identical-length tie-rods for balanced steering response.
Drivetrain And Gearing
- Multiple gear ratios via pinions: 18T (18.03:1), 20T (16.23:1), 17T (19.09:1).
- 20T and 17T pinion gears are sold separately.
Suggested Compatibility
- Wheelbase length and body mount positions match the long CC-02 layout, offering suggested compatibility with bodies designed around that configuration.
Secured by Stripe
Tamiya RC Squash Van (GF-02) Manuals & Guides
Manuals & Guides
How-To Guides & Articles
Specifications
Tamiya Release Date: 24/11/2023
Tamiya is delighted to announce a new off-road car featuring big tires; the name is the Squash Van, and it is paired with a new gear-driven 4WD GF-02 chassis.
While the GF-01 chassis features a comical design, the GF[1]02 chassis employs a more realistic wheelbase and a frame with ladder / pipe motifs. This R/C assembly kit is inspired by 1950s American panel vans, and offers an excellent drive even on grass or uneven surfaces.
About the Model
- This is a 1/10 scale R/C model assembly kit. Length: 454mm, width: 280mm, height: 238mm. Wheelbase: 267mm.
- 123mm large-diameter lug pattern tires allow powerful performance and superior handling feel.
- Stickers feature designs such as squash illustrations, product logo, and triple pin stripes in gold, black and blue.
- ESC & Type 540 Motor Included
About the GF-02 chassis
The gear-driven 4WD GF-02 chassis features its motor in a low, central position in the lightweight, durable monocoque frame, and transmits power to front and rear via gears. The long wheelbase and wide tread setup ensures stable off-road performance. The slim frame features ladder/pipe motifs and features integrated sealed gearboxes which help keep stones out.
Front and rear gear differentials allow smooth cornering, while separately sold pinion gears offer a choice from three types of gear ratios, and a motor guard enhances reliability off-road. The 4-wheel double wishbone suspension employs four friction dampers, and the steering servo is positioned on the left with identical-length tie-rods
Wheelbase
same length as the long CC-02 wheelbase chassis same body mount positions as the long CC-02 wheelbase chassis
Tread
F : 223mm / R: 221mm
Tyres
As Blackfoot [58633] 122.8mm diameter
Gear ratio
18T (18.03:1), 20T (16.23:1), 17T (19.09:1)
20T and 17T pinion gears are sold separately
Motor Guard included
Lower servo mount to enhance attachment durability and lower more central motor position for improved balance and weight distribution.
Key Info:
- Brand: Tamiya
- Part No: HC-58725
- Barcode: 4950344587254
- Scale: 1:10
- Power Source: Electric - Brushed
- Vehicle Type: Monster Truck
- Surface Type: Off Road
- Build Level: Unassembled (Kit)
Delivery & Returns
Free Shipping
This item is over £100, so qualifies for free standard UK shipping!
Express Shipping
Upgrade to next day from £3
Worldwide Shipping
Available at checkout
Customer Reviews
No specific product reviews yet, why not write one?Questions & Answers
Hi, yes you would need to buy the parts individually on the pro pack , for bearings you will need the following quantities and sizes
- (4) 5x8x2.5
- (32) 5x11x4
This will be a body that needs painting.
