APC Folding Electric Hub For 45mm Spinner

APC Folding Electric Hub For 45mm Spinner

Brand: APC

Part No: APCLPFH4

£5.65 RRP £5.95

Shadow Stock: Usually ships next day

Collect Instore
Request Price Match Ask a Question Write a Review

The APC Folding Electric Hub for 45mm Spinner (part number APCLPFH4, also referenced as LPFH4) is a two-piece, grey composite hub designed to secure APC folding propeller blades (blades not included). Intended for electric-powered aircraft only, it features moulded nut insets for easy tightening and comes complete with hardware. Suggested compatibility includes use with a 45mm spinner or similar.

Key Features

  • 50mm folding prop hub that adds 50mm to overall propeller diameter
  • Two-piece grey composite construction with moulded nut insets
  • Includes hardware (blades not included)
  • For electric powered aircraft only (not for gas engines)
  • Suggested compatibility: 45mm spinner or similar
  • Use LPAR18SF or LPARM12SF adapter rings for centring on smaller motor shafts (not included)

Technical Specifications

  • Overall length: 63mm
  • Length between blade mounting centres: 50mm
  • Inner mounting diameter: 8mm ID with 30° taper for collets
  • To fit motor shaft size: 3.2–9.5mm
  • Weight: 11.056g (0.39oz)
  • Shipping weight: 0.01kg (0.02lbs)
  • Application: Folding
  • Colour: Grey
Free Shipping

On UK Orders over £100
Happy to Help

Helpful, friendly advice
28 Day Returns

Easy returns process
Secure Payments

Secured by Stripe

50mm Folding Electric Hub for 45mm Spinner
APC Folding Propeller Hub 50mm LPFH4
Two-piece, gray composite propeller hub that goes on each side of the APC folding propeller blades to hold them in place.
(blades are not included)
The 50mm Folding Propeller Hub can be used with a 45mm spinner or similar.
Electric powered aircraft only (not for gas engines).
Hub has molded nut insets for easy tightening and includes hardware.
Overall Length: 63mm
Length between Blade Mounting Centers: 50mm
Inner Mounting Diameter: 8mm ID with 30 deg. taper for collets

Use LPAR18SF or LPARM12SF adapter rings for centering on smaller motor shafts (not included)

APC Folding Electric Hub For 45mm Spinner Key Features:

  • 50mm Folding Electric Hub for 45mm Spinner
    APC Folding Propeller Hub 50mm LPFH4
    Two-piece, gray composite propeller hub that goes on each side of the APC folding propeller blades to hold them in place.
    (blades are not included)
    The 50mm Folding Propeller Hub can be used with a 45mm spinner or similar.
    Electric powered aircraft only (not for gas engines).
    Hub has molded nut insets for easy tightening and includes hardware.
    Overall Length: 63mm
    Length between Blade Mounting Centers: 50mm
    Inner Mounting Diameter: 8mm ID with 30 deg. taper for collets

    Use LPAR18SF or LPARM12SF adapter rings for centering on smaller motor shafts (not included)
  • Hub adds 50mm to prop diameter.
  • To Fit Motor Shaft Size - 3.2 to 9.5mm

APC Folding Electric Hub For 45mm Spinner Tech Specs:

  • Weight: 11.056g / 0.39oz
  • Shipping Weight: 0.01kg / 0.02lbs
  • Application: Folding
  • Colour: Grey


    Key Info:
    • Brand: APC
    • Part No: APCLPFH4
    • Barcode: 686661500013
