Multiplex Rx-5 Light M-LINK 2.4GHz Receiver (MPX55808)
Brand: Multiplex
Part No: MPX55808
Shadow Stock: Usually ships next day
Finance options available at checkout.
Fits These Models (3)
Description
The Multiplex Rx-5 Light M-LINK 2.4 GHz receiver (MPX55808) is a compact five-channel unit featuring the UNI connector system. Its in-line connector layout and small footprint make it a tidy choice for space-limited installations across air, land and water models.
Key Features
- 2.4 GHz M-LINK FHSS reception
- HOLD / FAIL-SAFE function
- Integral button and LED for binding, FAIL-SAFE programming, reset and status indication
- UNI connector system with in-line sockets for neat wiring
- Lightweight design at approximately 7 g
Technical Specifications
- Servo channels: 5
- Operating voltage: 3.5 – 9.0 V
- Power supply: 4–5 NiXX cells, 2S LiPo / LiIo
- Operating temperature: -20°C to +55°C
- Dimensions (L × W × H): approx. 34 × 19.5 × 11 mm
- Weight: approx. 7 g
- Colour: Silver
- Age recommendation: 14+
Suggested Compatibility
- Model helicopters up to around 80 cm rotor diameter
- Electric and power aeroplanes up to about 1.3 m wingspan
- Gliders and electric gliders up to about 2 m wingspan
- RC model cars
- RC model boats
Secured by Stripe
Multiplex Receiver Rx-5 Light M-Link 2.4 Ghz 55808 Manuals & Guides
Manuals & Guides
Specifications
Small, reasonably priced five-channel 2.4 GHz M-LINK receiver with the UNI connector system. A compact case and small dimensions in conjunction with in-line connectors make this unit ideal for the smaller model.
Typical applications:
- Model helicopters up to around 80 cm rotor diameter
- Electric and power models up to about 1.3 m wingspan
- Gliders and electric gliders up to about 2 m wingspan
- RC model cars
- RC model boatsThe plus-points:
- HOLD / FAIL-SAFE function
- Integral button and LED for: Binding, FAIL-SAFE programming, RESET, Operating status information
| Servo channel count: | 5 |
| Reception system: | 2.4 GHz FHSS (Frequency |
| Hopping Spread Spectrum) | |
| Operating voltage: | 3.5 … 9.0 V |
| Power supply: | 4 - 5 NiXX cells, 2S LiPo / LiIo |
| Operating temperature range: | -20°C … +55°C |
| Dimensions (L x W x H): | approx. 34 x 19.5 x 11 mm |
| Weight: | approx. 7 g |
Multiplex Receiver Rx-5 Light M-Link 2.4 Ghz 55808 Tech Specs:
- Shipping Weight: 0.04kg / 0.09lbs
- Age Recommendation: 14+
- Colour: Silver
Key Info:
- Brand: Multiplex
- Part No: MPX55808
- Barcode: 4041033028087
- Frequency: 2.4Ghz
- Channels: 5 Channel
- Fitment: Option Part
