Multiplex ROXXY BL Outrunner D50-65-10 290kV MPX314666

Brand: Multiplex

Part No: MPX314666

£143.20 RRP £160.90

Usually ships next day

UK Delivery
Get it by Wednesday 25th Nov
Store Collection (Cannock)
Tuesday 24th Nov, once stock arrives

Finance options available at checkout.

Popular with customers who buy products like the ROXXY BL Outrunner (D50-65-10) - 290kV

Description

The Multiplex ROXXY BL Outrunner (D50-65-10) - 290kV, part number MPX314666, is a 14-pole brushless outrunner motor rated at 290kV and 2050W, with a 50 mm motor diameter and a 6 mm shaft.

As an outrunner with neodymium magnets, this motor needs no reduction gearbox. Its construction often allows it to drive large propellers directly, which suits direct-drive applications. Multiplex describes the windings as having a maximum copper fill ratio, aimed at efficient, high-torque running.

D series ROXXY motors use triple ballraces. A third, thin-section bearing is added to improve precision and smooth running, and it stops the motor bell distorting under load. The motor can be mounted from either end, and it is silver and made from aluminium. Multiplex gives an age recommendation of 14+.

Specifications

  • Speed constant: 290kV
  • Power: 2050W
  • Motor diameter: 50 mm
  • Length: 65 mm
  • Shaft diameter: 6 mm
  • Weight: 405 g

Specifications

14-pole brushless outrunner motors

Brushless motors with neodymium magnets represent the very latest form of electric power plant. Outrunners in particular require no reduction gearbox, and constitute efficient, high-torque motors covering a broad range of power levels.

The special construction of outrunner motors often enables them to drive large propellers without the need for a gearbox, so they are ideal for direct-drive applications.

  • Maximum copper fill ratio and superior neodymium magnets for high efficiency
  • Large, precision ballraces ensure smooth running
  • Can be mounted by either end

ROXXYå¨ BL outrunner motors of the D and CA series are equipped with triple ballraces. To improve precision and smooth-running, a third ballrace, known as a thin-section bearing, is fitted. This prevents the motor bell distorting under load, ensuring smooth running.

ROXXY BL Outrunner (D50-65-10) - 290kV Key Features:

  • 290kV
  • 2050W
  • 50mm motor diameter.
  • 6mm shaft diameter.

ROXXY BL Outrunner (D50-65-10) - 290kV Tech Specs:

  • Weight: 405g / 14.29oz
  • Shipping Weight: 0.57kg / 1.26lbs
  • Product Length: 65mm / 2.56in
  • Product Diameter: 50mm / 1.97in
  • Age Recommendation: 14+
  • Colour: Silver
  • Material: Aluminium


    Key Info:
    • Brand: Multiplex
    • Part No: MPX314666
    • Barcode: 4041033046661
