Schumacher Cougar LD3M - Mod Spec - Kit

The Schumacher Cougar LD3M – Mod Spec – Kit (SCH-K208) refines the class-leading LD3 1/10 2WD racing buggy platform. Lighter, more durable and easier to work on, the LD3 has already delivered national and international success, including a World Championship podium. The LD3M configuration is optimised for medium to high-grip astro and carpet tracks, featuring the forward motor position laydown transmission for precise, high-traction handling.

LD3M – Mod Spec Highlights

• New front quarter geometry: front wishbone, hub carrier with increased adjustability, and 5° caster block.
• Fine outboard camber link increments and greater range for front axle position.
• Larger hub bearings and updated axle design for durability; −2.0 mm front hex.
• S2 steering arms and improved pivot system for king pin and outer hinge pin.
• 4 mm S2 lightened front shock tower for lower centre of gravity; 4 mm S2 rear shock tower with new geometry.
• One-piece shock caps and moulded shock pistons for improved sealing and weight saving.
• 5.5 mm front camber link ball cups.
• 2.5 mm reduced-weight alloy chassis with recessed radio tray and redesigned rear end; side pods with rear flex slots for stiffness tuning.
• Internal transmission with twin-pad through slipper and 80T spur; moulded internal idler gear with improved Teflon-coated material.
• Revised differential shimming for durability.
• Rear suspension wishbones and alloy rear strap with greater wheelbase adjustment and new shock positions.
• Pin-retaining design for reliability; rear hub carrier with fully adjustable insert system and camber adjustment.
• Aerox Trident Wing 1.0 mm (AX037) and JConcepts S2 Cougar LD3 body (JC0432).

Key Features

• Class-leading front suspension geometry with durable components and optional alloy upgrades.
• Front end enables zero and minus five wheelbase lengths without needing an additional chassis.
• 90° phased lightweight steel CVD driveshafts – 65.5 mm.
• Easy-access battery fitting system with multiple mounting options; low drop wing mount.
• Compact steering layout for in-line weight placement with adjustable, dynamic Ackermann.
• 12 mm hex wheels with industry-standard offset.
• 13 mm big-bore shocks with CORE springs, threaded collars and twin O-ring sealing.
• Shock seal pack housing with O-ring sealing; lightweight lower spring cups; screw piston fixing with TiN shafts.
• Optional rear shock location in front of or behind the wishbones (as standard in the kit).
• Front shock tower cover to protect the car and track.
• Adjustable rear roll centres, inboard toe-in and anti-squat.
• Cable management system.
• Easy-access transmission for quick differential maintenance; spur gear shield.
• Small, low rotating mass transmission with 3-position height adjustment.
• Super-precision ball bearings throughout.

Specifications

• Power Source: Electric
• Model Type: 2WD, Off-Road, Competition
• Length: 395 mm
• Width: 245 mm
• Wheelbase: 275–285 mm
• Top Speed: 40+ mph

Required To Complete

• 2-channel radio
• Motor
• Servo
• Electronic speed control
• Tyres
• LiPo battery
• Paint for bodyshell
