Description
The XRay XP10 XR370507 is an XRay radio-controlled chassis platform designed around a narrow, one-piece chassis. This layout is intended to provide consistent handling and resistance to chassis tweak, while reducing drag during cornering. The rear pod sits on top of the chassis and includes a set screw for adjusting its angle. Its rear spring position supports forward traction, with droop adjustment controlled through the rear bump spring tension.
The two-piece lower pod plate mounts to the bulkheads and provides adjustment for droop and pod angle, while also supporting the side springs. An additional forward centre pivot position, low pivot holder and small-diameter pivot ball provide further adjustment options. The carbon-fibre top plate carries the centre shock and side damper mountings, with composite bushings used for hardware installation. A centre dampener with a one-hole piston is included for bump handling and low-maintenance operation.
Features
- Narrow one-piece chassis design
- Adjustable rear pod angle
- Rear spring location for forward traction
- Adjustable droop and pod angle
- Carbon-fibre top plate for centre shock and side dampers
- Adjustable centre pivot positions
Secured by Stripe
Specifications
- One-piece chassis design for consistent handling in all conditions and superior tweak resistance
- Narrow chassis shape for minimum chassis drag during cornering
- Rear pod concept on top of chassis for minimum drag and superior tweak resistance
- Adjustable pod angle controlled by set screw at the rear of chassis for fine tuning
- Rear spring location for maximum forward traction with great adjustability and low CG
- Rear droop adjustment through rear bump spring tension. The spring sits in a special composite adjuster
- Universal rear spring nut holder works for both conical and linear springs
- 2-piece lower pod plate mounts to the bulkheads, offering droop and pod angle adjustments with support for the side springs
- Ultra-light, low CG bulkheads are foundation of the pod system
- Extra forward center pivot position for maximum adjustability
- Low pivot holder and small diameter pivot ball offer low roll center positions and great adjustment range
- Carbon Fiber top plate for center shock and side damper mountings
- Rear carbon side spring brace aligns with the pod geometry
- Composite bushings press into carbon fiber parts for secure and reliable hardware installation
- Center dampener with 1-hole piston provides exceptional bump handling, low maintenance, and maintains a low CG
Key Info:
- Brand: XRay
- Part No: XR370507
- Barcode: 8581703705079
- Scale: 1:10
- Power Source: Electric - No Motor
- Surface Type: On Road
- Vehicle Type: Touring / Rally Car
- Build Level: Unassembled (Kit)
